h Rename
Change the display name for this source.
Names containing up to 8 characters can be input.
[Characters that can be input]
A ~ Z
a ~ z
0 ~ 9
! # % & ’ ( ) * + , - . / : ; = “ ? @ [ \ ] (space)
[Variable range]
–12dB
~
0dB
~
+12dB
For input sources for which “HDMI In” and “Digital In” are set at the
menu “Assign” setting, the analog input level and digital input level
can be set separately.
j Source Level
Corrects the playback level of the selected input source’s audio
input.
Default
Resets the settings to the default values.
For details on how to select, set and cancel settings for each menu, see “Menu Operations” (vpage 17).
k Assign
Assign input sources to input connectors.
HDMI In
Select HDMI connector to assign to this source.
[Input source]
DVD
HDP
TV/CBL
VCR
V.AUX
[Selectable items]
HDMI1
: Assign HDMI1 input connector.
HDMI2
: Assign HDMI2 input connector.
HDMI3
: Assign HDMI3 input connector.
HDMI4
: Assign HDMI4 input connector.
None
: No HDMI input connector assigned.
Input source DVD HDP TV/CBL VCR V.AUX
Default setting HDMI1 HDMI2 None HDMI3 HDMI4
• With HDMI, the video and audio signals are transferred
simultaneously. When HDMI is assigned to an input source, the
audio signal switches to HDMI along with the video signal. To use
with the digital audio input connectors assigned, set menu “Input
Mode” to “Digital”.
• When the AVR-2309 and monitor are connected with an HDMI cable,
if the monitor is not compatible with HDMI audio signal playback,
only the video signals are output to the monitor.
• The audio signals input from the analog, digital and EXT. IN connectors
are not output to the monitor.
Digital In
Select digital input connector to assign to this source.
[Input source]
CD
CDR/TAPE
DVD
HDP
TV/CBL
VCR
V.AUX
[Selectable items]
COAX1
: Assign COAXIAL 1 input connector.
COAX2
: Assign COAXIAL 2 input connector.
OPT1
: Assign OPTICAL 1 input connector.
OPT2
: Assign OPTICAL 2 input connector.
OPT3
: Assign OPTICAL 3 input connector.
None
: No digital input connector assigned.
Input source CD
CDR/
TAPE
DVD HDP TV/CBL VCR V.AUX
Default setting COAX2 None COAX1 None OPT1 OPT2 OPT3
Input source DVD HDP TV/CBL VCR V.AUX
Default setting 1-RCA 2-RCA 3-RCA None None
Component In
Select component video input to assign to this source.
[Input source]
DVD
HDP
TV/CBL
VCR
V.AUX
[Selectable items]
1-RCA
: Assign component video 1 input connector.
2-RCA
: Assign component video 2 input connector.
3-RCA
: Assign component video 3 input connector.
None
: No component video input connector assigned.
iPod dock
Assign control dock for iPod to this source.
[Input source]
CD
CDR/TAPE
DVD
HDP
TV/CBL
VCR
V.AUX
[Selectable items]
Assign
: Assign iPod input.
None
: Do not assign iPod input.
• With the default settings, the control dock for iPod can be used
connected to the VCR (iPod) connector.
• Even if “iPod dock” is set to “Assign”, if AVR-2309 and control dock
for iPod are not connected, the input is used as the normal input
source.
