Denon AVR-2310 Service Manual

101101
AVR-2310CI/2310/890, AVC-2310
OTHERS PARTS GROUP
BKT101 nsp BRACKET 0.8t/SCREW
4010210196100S
CLAMP101-103 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN101 nsp CN,WIRE 10P L000161100050S
CN104 nsp CN,WIRE 8P L002131080050S
CN201 nsp CN,WIRE 7P L002131070010S
CN511 nsp CN,WIRE 9P L000600090021S
CP103 nsp CN.WAFER 3P L102526700300S
CP104 nsp CN.WAFER 3CKT L108353280360S
CP105 nsp CN.WAFER 11P L101100041110S
CP106 nsp CN.WAFER 5P L101100040510S
CP107 nsp CN.WAFER 2P L102020010020S
CP108 nsp CN.WAFER 13P L101100041310S
CP109 nsp CN.WAFER 5P L101100040510S
CP541 nsp CN,WIRE 3P L000251030081S
CP707 nsp CN.WAFER 15P L101100041510S
GND101 nsp TERMINAL EARTH 3790040886000S
JACK101 00D9630325606 JACK,D3.5 EARPHONE 2310 G40130802001YS
JACK102 963643003560S TER,RCA-303B1-10 890E3 G606303B1100YS
JACK231,232 00D9630244703 JACK,D3.5 EARPHONE G40130802000YS
JK102 00D9630225803 TER,RCA RCA-206B-05 890EA G601206B0500YS
L101C 00D9630049005 COIL INDUCTOR 0.5UH D330R50000000S
L101FL 00D9630049005 COIL INDUCTOR 0.5UH D330R50000000S
L101FR 00D9630049005 COIL INDUCTOR 0.5UH D330R50000000S
L101SL 00D9630049005 COIL INDUCTOR 0.5UH D330R50000000S
L101SR 00D9630049005 COIL INDUCTOR 0.5UH D330R50000000S
L102 nsp BEAD,COIL 3580-52RE-AX 2310 7610010030000S
L231 nsp BEAD,COIL 3580-52RE-AX 7610010030000S
RLY541 00D9630218409 RELAY BC3-12 24V 2A G680240202030S
TP101-105 nsp CN.WAFER 3P L101530140310S
00D9630225803 TER,RCA 2PIN RCA-206B-05(RD,WH) 2310E2 G601206B0500YS
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-2310 Specifications

General

Equalizer	Yes
Product color	Black
Impedance	8 Ω
Frequency range	10 - 100000 Hz
Total Harmonic Distortion (THD)	0.05 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
S-Video inputs quantity	7
Component video (YPbPr/YCbCr) in	3
Dimensions (WxDxH)	431 x 377 x 171 mm
HDMI ports quantity	5
Connectivity technology	Wired
Headphone connectivity	3.5 mm
S-Video outputs quantity	2
Digital audio optical out	1

Weight and Dimensions

Weight	11200 g
