Denon AVR-2310 Service Manual

102102
AVR-2310CI/2310/890, AVC-2310
PCB POWER ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC501 00D9600262605 IC NJM2396F05
J126239600010S
IC502 00D9600195808 IC ICP-N15 J120001500030S
IC511 00D2631274012 IC NJM2396F09 J126239600090S
IC512 00D2630553006 IC NJM7805FA J126780500130S
IC513 00D2630554005 IC NJM7905FA J126790500020S
IC514 00D2630553006 IC NJM7805FA J126780500130S
IC516 00D2630641002 IC NJM7912FA J126791200080S
Q501 00D9600196409 TR 2SC1740SR J5021740S0010S
Q502 00D9630121208 TR KRC107M J6020107M0010S
Q503 00D9600196409 TR 2SC1740SR J5021740S0010S
Q511 00D9630327905 TR 2SB KTB778 J501778000010S
Q512 00D9630328205 TR 2SD KTD998 J503998000010S
Q513 90M-HT100330R TR 2SA KTA1267Y J5001267Y0050S
Q514 00D9600097304 TR KRC102M J6020102M0010S
Q515 00D9630255802 TR KTC3199Y J5023199Y0010S
Q516 90M-HT100330R TR 2SA KTA1267Y J5001267Y0050S
Q517 00D9630327808 TR KTA1281Y J5001281Y0010S
Q518 00D9600097304 TR KRC102M J6020102M0010S
Q519 00D9630328001 TR 2SC KTC3209Y J5023209Y0010S
Q520 90M-HT100330R TR 2SA KTA1267Y J5001267Y0050S
D501-503 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D504-507 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D508-512 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D513-520 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D521,522 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D523-526 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D535,536 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D537 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D538,539 00D9630236504 D,SWITCHING AX-52 K120072140010S
ZD501 00D9600095500 D,ZENER MTZJ5.1B K06005R144520S
ZD502 00D9630058601 D,ZENER MTZJ12B K06012R044520S
ZD503,504 00D9600096004 D,ZENER MTZJ33B K06033R044520S
RESISTORS GROUP
R507 00D2412376964 R,METAL 47-J,1/4W-R
C060047063050S
R511,512 00D9630337908 R,METAL 33-J,1W C060033065050S
R516-519 00D9639006269 R,FIXED RSD-R1-1WJ-0.22 N113135622820S
R521 00D9630048103 R,METAL 150-J,1W-R C060015165050S
CAPACITORS GROUP
C501 963134001860S C,ELECT 470UF-M/16V
D040471083080S
C502 00D9630217002 C,ELECT 3300UF-M/16V D040332083010S
C503 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C504 00D9630323802 C,CERAMIC AC(SAFETY) 0.0047UF 250VAC D00847208H010S
C505 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C506,507 963134001820S C,ELECT 1000UF-M/35V D040102085030S
C511-516 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C517 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C518 00D9630217002 C,ELECT 3300UF-M/16V D040332083010S

Denon AVR-2310 Specifications

General

Equalizer	Yes
Product color	Black
Impedance	8 Ω
Frequency range	10 - 100000 Hz
Total Harmonic Distortion (THD)	0.05 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
S-Video inputs quantity	7
Component video (YPbPr/YCbCr) in	3
Dimensions (WxDxH)	431 x 377 x 171 mm
HDMI ports quantity	5
Connectivity technology	Wired
Headphone connectivity	3.5 mm
S-Video outputs quantity	2
Digital audio optical out	1

Weight and Dimensions

Weight	11200 g
