Denon AVR-2310 Service Manual

137
AVR-2310CI/2310/890, AVC-2310
B15 - PCB REG ASSY 7020068920000S 2*
1 963416004500D WINDOW DISPLAY
5077212762040S 1*
2 963412000570D KNOB FUNCTION(KD) BK
5080211761000SZ 1
2 963412003660D KNOB FUNCTION SP
5087211901000S 1
3 00D9630362109 BADGE DENON BK
5630210028300S 1
3 00D9630362202 BADGE DENON SP
5630210028400S 1
4 963402004490D PANEL FRONT 2310CIBKE3
3067214351300S 1*
4 963402004700D PANEL FRONT 2310BKE2
3067214351400S 1*
4 963402004760D PANEL FRONT 2310SPE2
3067214351500S 1*
4 963402004820D PANEL FRONT 890BKE3
3067214371200S 1*
4 963402004850D PANEL FRONT 890BKEA
3067214371300S 1*
4 963402004930D PANEL FRONT 2310SPE1C
3067214351510S 1*
5 00D9630137807 LENS STANDBY
3710210503000S 1
6 963411004710D BUTTON POWER BK
5090213821000S 1
6 00D9630230005 BUTTON POWER SP
5097212358300SZ 1
7 963411002820S BUTTON STANDBY(KD) BK
5098212361000SZ 1
7 00D9630221904 BUTTON STANDBY SP
5097212368030SZ 1
8 00D9630362305 BUTTON 2KEY 2310BK
5097213351000S 1
8 00D9630362501 BUTTON 2KEY 2310SP
5097213351110S 1
8 963411001390D BUTTON 2KEY 890BK
5097213591000S 1
9 963409002050D SHEET WINDOW
1210210682000S 1
10 963419004680D COVER RCA BK
4317214571000S 1*
10 963419004740D COVER RCA SP
4317214571100S 1*
11 963412000560D KNOB VOLUME(KD) BK
5080211751000SZ 1
11 963412002920S KNOB VOLUME SP
5087211891000S 1
12 963411003370D BUTTON 1KEY 2310BK
5097213791000S 1
12 963412003670D BUTTON 1KEY 2310SP
5097213791100S 1
12 963411003770D BUTTON 1KEY 890BK
5097213801000S 1
13 963411003380D BUTTON CURSOR 5KEY BK
5097213811000S 1
13 963411003680D BUTTON CURSOR 5KEY SP
5097213811100S 1
14 00D9630364700 BUTTON 3KEY 2310BK
5097213331000S 2
14 00D9630364906 BUTTON 3KEY 2310SP
5097213331110S 2
14-1 963411001400D BUTTON 3KEY A 890BK
5097213601000S 1
14-2 963411001410D BUTTON 3KEY B 890BK
5097213611000S 1
15 00D9630365002 BUTTON WIN 3KEY BK
5097213371000S 2
15 00D9630365301 BUTTON WIN 3KEY SP
5097213371110S 2
16 963411003400D BUTTON WIN 3KEY C BK
5097213831000S 1
16 963411003690D BUTTON WIN 3KEY C SP
5097213831100S 1
17 nsp CLAMP WIRE(MTG)
4330000310000S 1
18 nsp TAPE ACETATE CLOTH
1220210199010S 1
19 nsp HEAT SINK
2120211658000S 1
20 nsp BRACKET PCB
4010210186000S 3
21 nsp BRACKET HEATSINK R
4010213136000S 1
22 nsp BRACKET HEATSINK L
4010213146000S 1
23 963252004340S POSISTOR
F320121021240S 1
24 nsp CHASSIS MAIN 2310
3200212146100S 1
24 nsp CHASSIS MAIN 890
3200212146101S 1
25 963407003330D FOOT
4000210261000S 4
26 nsp BRACKET TRANS
4010210466002S 1
27 nsp BRACKET SAFETY
4010213606000S 1
28 00D9630214607 CUSHION FOOT
4050211295000S 4
29 nsp SUPPORTER PCB
4070001601010S 3
z 30 963101004790D POWER TRANS MAIN E3
8200960660560S 1*
z 30 963101004750D POWER TRANS MAIN E2, EA
8200960660570S 1*
z 30 963101004890D POWER TRANS MAIN E1C
8200960660580S 1*
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-2310 Specifications

General

Equalizer	Yes
Product color	Black
Impedance	8 Ω
Frequency range	10 - 100000 Hz
Total Harmonic Distortion (THD)	0.05 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
S-Video inputs quantity	7
Component video (YPbPr/YCbCr) in	3
Dimensions (WxDxH)	431 x 377 x 171 mm
HDMI ports quantity	5
Connectivity technology	Wired
Headphone connectivity	3.5 mm
S-Video outputs quantity	2
Digital audio optical out	1

Weight and Dimensions

Weight	11200 g
