Denon AVR-2310 Service Manual

138
AVR-2310CI/2310/890, AVC-2310
31 nsp CUSHION SIDE 4050211095000S 3
32 nsp CN WIRE
L000121020230S 1
z 33 00D9630158404 AC INLET
G430040560020S 1
34 963406004690D CHASSIS BACK 2310CIBKE3
3207212876000S 1*
34 963406004940D CHASSIS BACK 2310BKE2/SPE2
3207212876200S 1*
34 963406004950D CHASSIS BACK 890BKE3
3207212876100S 1*
34 963406004960D CHASSIS BACK 890BKEA
3207212876300S 1*
34 963406004970D CHASSIS BACK 2310SPE1C
3207212876400S 1*
35 nsp TERMINAL
3790000090000S 1
36 00D2160124109 TUNER PACK E3
E903014000020S 1
36 00D9630145705 TUNER PACK E2, EA
E903014100030S 1
37 nsp CUSHION BD
4050211845000S 1
38
39 00D9630361302 CABINET TOP BK
3000210936000S 1
39 963401000730D CABINET TOP SP
3000210936200S 1
40 963409001780D COVER SAFETY BKE2, BKEA
4310212122020S 1
40 963409001790D COVER SAFETY SPE2, SPE1C
4310212122010S 1
41 963454001800D COVER HOLDER BKE2, BKEA
4310213701000S 6
41 963454001810D COVER HOLDER SPE2, SPE1C
4310213701100S 6
42 nsp BRACKET HDMI
4010214556000S 1*
43 nsp SUPPORTER PCB
4070211653000S 1
44 nsp CUSHION INPUT
4050212565000S 1*
45 nsp GASKET EMC A
4400210179000S 2
46 nsp GASKET EMC A
4400210189000S 3
47 nsp SHEET CABINET
1210210235000S 3
49 nsp SPACER CARD
4300210062000S 1
50 nsp SUPPORTER
4420010223010S 1
★ 51
00D9630235204 TR PNP 2SB 2SB1647Y
J5011647Y0170S 5
★ 52
963219003340S TR NPN 2SC KTC3964
J502396400010S 5
★ 53
00D9630235301 TR NPN 2SD 2SD2560Y
J5032560Y0170S 5
★ 54
nsp LABEL FUSE CAUTION E3
5507000001110S 1
★ 55
nsp CLAMP
4330040343010S 10
WIRES
★ 61
963606005150S CABLE,FLAT CARD 1.0MM
N711061233810S 1
★ 62
963606005160S CABLE,FLAT CARD 1.0MM
N711071333810S 1
★ 63
963606005170S CABLE,FLAT CARD 1.0MM
N711119543810S 1
★ 64
963606005180S CABLE,FLAT CARD 1.0MM
N711129543810S 1
★ 65
963606005190S CABLE,FLAT CARD 1.0MM
N711149543810S 1
★ 66
963606005200S CABLE,FLAT CARD 1.0MM
N711159543810S 1
★ 67
963606005210S CABLE,FLAT CARD 1.0MM
N711193343810S 1
★ 68
963606005220S CABLE,FLAT CARD 1.0MM
N711233343810S 1
★ 69
963606005230S CABLE,FLAT CARD 1.25MM E3, E2, EA
N712150634811S 1
★ 70
963606000600S CABLE,FLAT CARD SHIELD 1.25MM
N714351634810S 1
SCREWS
A nsp SCREW (+2S 3*8 B-TYPE ZNW/BH)
B020030081B10S 71
B nsp SCREW (+2S 3*8 BK WASHER PI12) BK
1500001456020S 5
B nsp SCREW (+2S 3*8 NI WASHER PI12) SP
1500001456030S 5
D nsp SCREW (+2S 3*10 B-TYPE(DOT) BK/BH) E3
B020030103B11S 44
D nsp SCREW (+2S 3*10 B-TYPE(DOT) BK/BH) E2
B020030103B11S 46
D nsp SCREW (+2S 3*10 B-TYPE(DOT) BK/BH) EA
B020030103B11S 43
D nsp SCREW (+2S 3*10 B-TYPE(DOT) BK/BH) E1C
B020030103B11S 42
Ensp
SCREW (+2S 3*14 P( Φ 6)+S-WASHER ZNY/HH)
B018230141H11S 21
F nsp SCREW (+2S 3*17 B-TYPE ZNW/BH)
B020030171B10S 3
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-2310 Specifications

General

Equalizer	Yes
Product color	Black
Impedance	8 Ω
Frequency range	10 - 100000 Hz
Total Harmonic Distortion (THD)	0.05 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
S-Video inputs quantity	7
Component video (YPbPr/YCbCr) in	3
Dimensions (WxDxH)	431 x 377 x 171 mm
HDMI ports quantity	5
Connectivity technology	Wired
Headphone connectivity	3.5 mm
S-Video outputs quantity	2
Digital audio optical out	1

Weight and Dimensions

Weight	11200 g
