AVR-2801/981
SPECIFICATIONS
AUDIO SECTION
(Power Amplifier)
Rated output: Front: 90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
135 W + 135 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Center: 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
135 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround: 90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
135 W + 135 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Dynamic power: 120 W × 2 ch (8 Ω/ohms)
170 W × 2 ch (4 Ω/ohms)
200 W × 2 ch (2 Ω/ohms)
Output terminals: Front: A or B 6 ∼ 16 Ω/ohms
A+B 8 ∼ 16 Ω/ohms
Surround/Center: 6 ∼ 16 Ω/ohms
(Analog)
Input sensitivity/input impedance: 200 mV/47 kΩ/kohms
Frequency response: 10 Hz ~ 100 kHz: +0, −3 dB (DIRECT mode)
S/N: 102 dB (DIRECT mode)
Distortion: 0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
Rated output: 1.2 V
(Digital)
D/A output: Rated output − 2 V (at 0 dB playback)
Total harmonic distortion - 0.008% (1 kHz, at 0 dB)
S/N ratio − 102 dB
Dynamic range - 96 dB
Digital input: Format − Digital audio interface
(Phono equalizer (PHONO input-REC OUT))
Input sensitivity: 2.5 mV
RIAA deviation: ±1 dB (20 Hz to 20 kHz)
Signal-to-noise ratio: 74 dB (A weighting, with 5 mV input)
Rated output/Maximum output: 150 mV/7 V
Distortion factor: 0.03% (1 kHz, 3 V)
VIDEO SECTION
(Standard Video Jacks)
Input/output level and impedance: 1 Vp-p, 75 Ω/ohms
Frequency response: 5 Hz ~ 10 MHz − +0, −3 dB
(S-video jacks)
Input/output level and impedance: Y (brightness) signal − 1 Vp-p, 75Ω/ohms
C (color) signal − 0.286 Vp-p, 75Ω/ohms
Frequency response: 5 Hz ~ 10 MHz − +0, −3 dB
TUNER SECTION
[FM] (Note: µV at 75 Ω/ohms, 0 dBf = 1 × 10
-15
W) [AM]
Receiving range: 87.50 MHz ~ 107.90 MHz 520 kHz ~ 1710 kHz
(for North America model) (for North America model)
87.50 MHz ~ 108.00 MHz 522 kHz ~ 1611 kHz
(for Europe, China, Hong Kong, (for Europe, China, Hong Kong,
Taiwan R.O.C. and Multiple voltage models
)
Taiwan R.O.C. and Multiple voltage models
)
Usable sensitivity: 1.0 µV (11.2 dBf) 18 µV
50 dB quieting sensitivity: MONO 1.6 µV (15.3 dBf)
STEREO 23 µV (38.5 dBf)
S/N ratio: MONO 80 dB
STEREO 75 dB
Total harmonic distortion: MONO 0.15 %
STEREO 0.3 %
GENERAL
Power supply: AC120 V, 60 Hz (for North America and Taiwan R.O.C. models)
AC230 V, 50 Hz (Europe model)
AC220 V, 50 Hz (for China model)
AC115/230 V, 50/60 Hz (for Hong Kong and Multiple voltage)
Power consumption: 5.0 A (for North America model)
270 W (for Europe, China, Hong Kong, Taiwan R.O.C. and Multiple voltage models
)
Maximum external dimensions: 434 (W) × 171 (H) × 416 (D) mm (17-3/32″ × 6-11/32″ × 16-3/8″)
Weight: 11.5 kg (25 lbs. 6 oz.)
REMOTE CONTROL UNIT (RC-881: for North America, China, Hong Kong, Taiwan R.O.C. and Multiple voltage models)
(RC-882: for Europe model)
Batteries: R6P/AA Type (two batteries)
External dimensions: 70 (W) × 215 (H) × 24 (D) mm (2-3/4″× 8-15/32″ × 15/16″)
Weight: 200 g (Approx. 7 oz.) (including batteries)
SAFETY PRECAUTIONS
The following check should be performed for the continued protection of the customer and service technician.
LEAKAGE CURRENT CHECK
Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis
resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the
power cord is less than 460 kohms, the unit is defective.
