46
AVR-2801/981
Ref. No. Part No. Part Name Remarks Q'ty
OTHER PARTS GROUP
AC501 203 3976 002 AC outlet (2P) for E3,EU,EUT 1
CW121 205 0885 079 12P connector socket (TUC-P) 1
CX021 205 0581 001 2P VH connector base
for E2,E1,E1C,E1H,EUT
1
CX022 205 0768 002 2P VH connector base (BLK) 1
CX023 205 1093 006 2P VH connector base for E2,E1 1
CX024 205 0581 001 2P VH connector base 1
CX031 205 0343 032 3P connector base (KR-PH) 1
CX032 205 0841 000 3P AC connector base (BK) for E1,E1H 1
CX033 205 0825 000 3P AC connector base 1
CX054~057 205 0884 009 5P connector base (TUC-P) 4
CX074 205 0943 021 7P connector base (TUC-P) 1
CX085 205 0884 096 8P connector base (TUC-P) 1
CX092 205 0884 038 9P connector base (TUC-P) 1
CX960~969 205 1064 064 6P pin header (TXX)V 10
F1 206 1046 001 Fuse 6.3A UL 20mm for E3,EU,EUT 1
F1 206 1015 074 Fuse 3.15A for E2,E1C 1
F1 206 1036 011 Fuse 6.3A for E1,E1H 1
F8 206 1046 014 Fuse 8A for E3,EU,EUT 1
F8 206 1015 032 Fuse 2.5A
for E2,E1,E1C,E1H
1
FF501,502 202 0040 909 Fuse clip 2
FH501,502 202 0040 909 Fuse clip 2
JK401 204 8516 017 3P pin jack 1
JK402 204 8583 008 2P pin jack (video) 1
JK403 204 8516 017 3P pin jack 1
JK601 205 0472 026 8P SP terminal (EAEK) 1
JK603 205 1108 001 6P SP terminal (E3) 1
RL501 214 0200 001 Relay EC2-12N35 1
RL502~505 214 0195 006 Relay FTR-F1 4
RL506 214 0188 000 Relay VS-12MBNR-SM2(TV-8) 1
T501 233 6073 107 Power trans. (Mini)-E3 for E3,EU,EUT 1
T501 233 6058 025 Power trans. (Mini)-E2 for E2,E1C 1
T501 233 6278 009 Power trans. (Mini)-E1 for E1,E1H 1
TP501-505 205 0133 035 3P NH connector base 5
TP510 205 0133 035 3P NH connector base 1
513 2585 074 Fuse label for F8 1
for E2,E1,E1C,E1H
513 2585 045 Fuse label for F1 1
for E2,E1C
513 2654 057 Fuse label for F1 1
for E1,E1H
415 0299 000 Condenser cover for C648 1
for E2,E1,E1C,E1H
Ref. No. Part No. Part Name Remarks
1U-3233 EXT. UNIT ASS'Y
SEMICONDUCTORS GROUP
IC101 262 2549 002 IC LC75721E
IC102 499 0290 007 Remocon sensor GP1U271X
IC103 262 2375 904 IC TC4094BF(TP1)
IC302 263 1103 905 IC UPC4570G2-E1
IC308~310 263 1103 905 IC UPC4570G2-E1
IC311 262 1853 100 IC NJU7313AL
IC701 263 1103 905 IC UPC4570G2-E1
IC801~803 263 1103 905 IC UPC4570G2-E1
IC805~807 262 2662 002 IC TC9459N
TR102~110 269 0082 902 Transistor DTC114EKT96
TR111 269 0083 901 Transistor DTA114EKT96
TR112 269 0055 900 Transistor DTA144EKT96
TR113~115 269 0054 901 Transistor DTC144EKT96
TR116,117 269 0055 900 Transistor DTA144EKT96
TR301~304 273 0414 906 Transistor 2SC3326(A/B)
TR305 269 0055 900 Transistor DTA144EKT96
TR306 269 0054 901 Transistor DTC144EKT96
TR308 275 0100 902 Transistor 2SK771-5-TB
TR311,312 273 0414 906 Transistor 2SC3326(A/B)
TR314,315 273 0414 906 Transistor 2SC3326(A/B)
TR323~326 273 0414 906 Transistor 2SC3326(A/B)
TR327,328 275 0100 902 Transistor 2SK771-5-TB
TR329 269 0054 901 Transistor DTC144EKT96
TR330 269 0055 900 Transistor DTA144EKT96
TR801~803 275 0100 902 Transistor 2SK771-5-TB
TR805 269 0083 901 Transistor DTA114EKT96
TR807 269 0054 901 Transistor DTC144EKT96
D104 276 0644 937 Zener diode MTZJ9.1A T77
D109 276 0432 903 Diode 1SS270A TE (TAPE)
D110,111 276 0559 909 Diode DAP202KT146
D304 276 0559 909 Diode DAP202KT146
D323,324 276 0432 903 Diode 1SS270A TE (TAPE)
D801~803 276 0432 903 Diode 1SS270A TE (TAPE)
LD102~110 393 9434 906 LED SEL1210S
RESISTORS GROUP
R101 247 0005 905 Carbon chip 100 ohm 1/10W RM73B--101JT
R102~110 247 0007 903 Carbon chip 680 ohm 1/10W RM73B--681JT
R111 247 0005 905 Carbon chip 100 ohm 1/10W RM73B--101JT
R112 247 0007 945 Carbon chip 1 kohm 1/10W RM73B--102JT
R113 247 0005 976 Carbon chip 200 ohm 1/10W RM73B--201JT
