AVR-2801/981
PARTS LIST OF P.W.B. UNIT
1U-3323 AUDIO/DSP UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
R137,138 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT
for E2,EUT
R139,140 247 2015 964 Carbon chip 2.7 Mohm 1/16W RM73B--275KT
R149,150 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
for E3,EU,E1,E1C,E1H
R149,150 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT
for E2,EUT
R151,152 247 2015 964 Carbon chip 2.7 Mohm 1/16W RM73B--275KT
R161,162 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
for E3,EU,E1,E1C,E1H
R161,162 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT
for E2,EUT
R163~166 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT
R167,168 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT
R169,170 247 2004 920 Carbon chip 47 ohm 1/16W RM73B--470JT
R171,172 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT
R173,174 247 2015 964 Carbon chip 2.7 Mohm 1/16W RM73B--275KT
R175,176 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT
R177,178 247 2015 964 Carbon chip 2.7 Mohm 1/16W RM73B--275KT
R179,180 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT
R181,182 247 2015 964 Carbon chip 2.7 Mohm 1/16W RM73B--275KT
R183,184 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT
R187~190 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT
R191,192 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
R195,196 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R197~200 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
R201,202 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT
R223,224 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R301,302 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R304 247 2009 909 Carbon chip 4.7 kohm 1/16W
RM73B--472JT (1608)
R305~309 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R311~328 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R331 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R334 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R335,336 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R337 247 2011 942 Carbon chip 47 kohm 1/16W RM73B--473JT
R338 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R342 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R345,346 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R349~351 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R352,353 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R701~703 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R705~707 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R708~710 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R711 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R713,714 247 2008 984 Carbon chip 3.9 kohm 1/16W RM73B--392JT
R715,716 247 2008 900 Carbon chip 1.8 kohm 1/16W RM73B--182JT
R717,718 247 2008 984 Carbon chip 3.9 kohm 1/16W RM73B--392JT
R719,720 247 2008 900 Carbon chip 1.8 kohm 1/16W RM73B--182JT
SEMICONDUCTORS GROUP
IC106 263 1103 905 IC UPC4570G2-E1
IC107 262 2545 006 IC TC9274N-011
IC108 262 2033 000 IC TC9273N-004
IC109 263 1103 905 IC UPC4570G2-E1
IC301 262 2840 002 IC TMP93CS40F-1B32
IC701~703 262 2747 901 IC AD1854JRSRL
IC731~733 263 1103 905 IC UPC4570G2-E1
IC800 262 2675 015 IC LC89055W-RA8
IC801 262 2608 901 IC TC74VHC123AFT
IC804 262 2609 900 IC SN74AHC157PW
IC805 262 2284 901 IC TC74HCT157AF(TP1)
IC806 262 2608 901 IC TC74VHC123AFT
IC807,808 262 2519 906 IC SN74LV00APW-EL2
IC809 262 2557 900 IC SN74LV14APW-EL2
IC811 263 0934 900 IC BA4510F-E2
IC812 262 2781 909 IC SN74LV4040APW-EL2
IC813 262 2772 905 IC AK5353
IC814 262 2657 907 IC CS492604-CLR
IC815,816 262 2660 907 IC SN74AHC574PW
IC817 262 2750 901 IC AD1854JRSRL
IC819 263 1048 002 IC BA033T
IC821 262 2685 908 IC SN74AHCT1G08DBV
TR305 269 0082 902 Transistor DTC114EKT96
TR702 269 0082 902 Transistor DTC114EKT96
TR703~712 269 0083 901 Transistor DTA114EKT96
D701~703 276 0560 901 Diode DAN202KT146
RESISTORS GROUP
R101,102 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
for E3,EU,E1,E1C,E1H
R101,102 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT
for E2,EUT
R103,104 247 2015 964 Carbon chip 2.7 Mohm 1/16W RM73B--275KT
R113,114 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
for E3,EU,E1,E1C,E1H
R113,114 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT
for E2,EUT
R115,116 247 2015 964 Carbon chip 2.7 Mohm 1/16W RM73B--275KT
R125,126 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
for E3,EU,E1,E1C,E1H
R125,126 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT
for E2,EUT
R127,128 247 2015 964 Carbon chip 2.7 Mohm 1/16W RM73B--275KT
R137,138 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
for E3,EU,E1,E1C,E1H
Note: The symbols in the column "Remarks" indicate the following destinations.
E3: U.S.A. & Canada model E1C: China model
EU: U.S.A. model (AVR-981) E1H: Hong Kong model
E2: Europe model EUT: Taiwan R.O.C. model
E1: Asia model
