49
AVR-2801/981
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
C823 255 1265 923 Mylar film 8200pF/50V CQ93M1H822JT(B)
C829,830 254 4538 900 Electrolytic 10
µ
F/16V
CE04W1C100MT SMG/RE3
C837,838 254 4524 943 Electrolytic 1
µ
F/50V
CE04W1H010MT SMG/RE3
C860 254 4524 943 Electrolytic 1
µ
F/50V
CE04W1H010MT SMG/RE3
C861,862 254 4538 900 Electrolytic 10
µ
F/16V
CE04W1C100MT SMG/RE3
for E3,EU,E1,E1C,E1H,EUT
C861,862 254 4538 939 Electrolytic 47
µ
F/16V
CE04W1C470MT SMG/RE3
for E2
C863~866 254 4538 900 Electrolytic 10
µ
F/16V
CE04W1C100MT SMG/RE3
C869,870 254 4524 985 Electrolytic 10
µ
F/50V
CE04W1H100MT SMG/RE3
for E3,EU,E1,E1C,E1H,EUT
C869,870 254 4538 939 Electrolytic 47
µ
F/16V
CE04W1C470MT SMG/RE3
for E2
C871 254 4524 985 Electrolytic 10
µ
F/50V
CE04W1H100MT SMG/RE3
C873,874 254 4524 985 Electrolytic 10
µ
F/50V
CE04W1H100MT SMG/RE3
OTHER PARTS GROUP Q'ty
CW052 205 0885 008 5P connector socket (TUC-P) 1
CW063 205 0942 019 6P connector socket (TUC-P) 1
CW079 205 0942 022 7P connector socket (TUC-P) 1
CW083 205 0885 095 8P connector socket (TUC-P) 1
CW091 205 0885 037 9P connector socket (TUC-P) 1
CW101 205 1000 002 10P FJ connector plug 1
CW112 205 0885 066 11P connector socket (TUC-P) 1
CW123 205 0885 079 12P connector socket (TUC-P) 1
CW161,162 205 1055 028 16P connector base (TKC-V) 2
CX932 205 1121 033 3P connector base-L (5268) 1
CY021 205 0581 001 2P VH connector base for E2,E1,E1C, 1
E1H,EUT
JK701 204 8545 004 4P pin jack (GND) 1
L701,702 235 9003 002 FTZ choke coil for E2,EUT 2
S101~112 212 5611 903 Tact switch 12
S113 212 0373 000 Rotary encoder EC16B 1
S114 212 0422 003 Rotary encoder 1
S901 212 1030 009 Power switch (TV-5) for E2,E1,E1C, 1
1E1H,EUT
ST2 205 0452 004 Style pin 1
W724 203 0526 002 1P contact ass'y 1
414 0799 109 Shield plate 1
203 0525 029 1P SIN cord ass'y W726 to W727 1
1U-3321 CONTROL UNIT ASS'Y
SEMICONDUCTORS GROUP
IC102 262 2616 003 IC TC9184AP
IC103,104 263 1103 905 IC UPC4570G2-E1
IC301 262 1701 906 IC SAA6579T-T for E2
IC302 262 1929 908 IC LC7074M-TE-R for E2
IC303 262 2839 000 IC TMP88CU74F-1B28
IC304 263 1040 903 IC BU4094BCF-E2
IC701~703 269 0178 007 Optical connector GP1F37R1
IC704 262 1205 907 IC TC74HCU04AF(TP1)
IC705 262 2386 906 IC SN74HC151NS(TAPE)
TR301 274 0163 904 Transistor 2SD601A
TR302 271 0299 905 Transistor 2SA1505Y-RTK
TR303 269 0054 901 Transistor DTC144EKT96
TR304 269 0082 902 Transistor DTC114EKT96
TR305 269 0055 900 Transistor DTA144EKT96
TR306 269 0054 901 Transistor DTC144EKT96
TR307 269 0083 901 Transistor DTA114EKT96
TR308,309 269 0054 901 Transistor DTC144EKT96
TR901 271 0131 924 Transistor 2SA988-T(E/F)
TR902 274 0160 907 Transistor 2SD2144STPU
TR903 273 0429 904 Transistor 2SC3311A (TA)
TR904,905 271 0131 924 Transistor 2SA988-T(E/F)
TR906~908 269 0083 901 Transistor DTA114EKT96
TR910 269 0083 901 Transistor DTA114EKT96
TR911 271 0131 924 Transistor 2SA988-T(E/F)
TR912 269 0083 901 Transistor DTA114EKT96
D301 276 0432 903 Diode 1SS270A TE (TAPE) for E2
D302 276 0432 903 Diode 1SS270A TE (TAPE)
D303 276 0634 905 Zener diode MTZJ3.3AT77
D304 276 0432 903 Diode 1SS270A TE (TAPE)
D305,306 276 0704 903 Diode 1SR35-400A(T93X)
D701 276 0432 903 Diode 1SS270A TE (TAPE)
D901~912 276 0432 903 Diode 1SS270A TE (TAPE)
D913 276 0704 903 Diode 1SR35-400A(T93X)
D914 276 0645 978 Zener diode MTZJ36A T77
D915 276 0704 903 Diode 1SR35-400A(T93X)
D916 276 0643 996 Zener diode MTZJ5.6A T77
D917 276 0704 903 Diode 1SR35-400A(T93X)
RESISTORS GROUP
R101,102 247 2008 968 Carbon chip 3.3 kohm 1/16W RM73B--332JT
R103,104 247 2006 986 Carbon chip 560 ohm 1/16W RM73B--561JT
R105,106 247 2013 982 Carbon chip 470 kohm 1/16W RM73B--474JT
R107,108 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
R109,110 247 2012 909 Carbon chip 82 kohm 1/16W RM73B--823JT
