58
AVR-2801/981
Ref. No. Part No. Part Name Remarks
Q'ty
61 513 2481 000 Serial no. sheet (T) for EUT 1
SCREWS
101 473 7500 015 Screw 3
×
8 CBTS (P)-Z 17
102 473 7501 001 Screw 3
×
10 CBTS (P)-Z 11
104 473 7015 018 Screw 3
×
8 CBTS (S)-B for E3,EU,EUT 10
for E2,E1,E1C,E1H 12
105 473 7005 002 Screw 3
×
10 CBTS (S)-Z 26
106 473 8007 009 Cup screw 3
×
12 10
107 473 7004 016 Screw 4
×
6 CBTS (S)-Z 4
108 473 8064 000 Screw 4
×
8 CBTS(B)-B-3P for Black model 6
108 473 8064 013 Screw 4
×
8 CBTS(B)-N-3P for Gold mode 6
109 477 0064 107 Fixing screw
for E3,EU,E1,E1H,EUT
30
for E2 26
for E1C 28
111 473 7006 056 Screw 3X20 CBTS (S)-B 1
PARTS LIST OF EXPLODED VIEW
Ref. No. Part No. Part Name Remarks
Q'ty
Ref. No. Part No. Part Name Remarks
Q'ty
Note: The symbols in the column "Remarks" indicate the following destinations.
E3: U.S.A. & Canada model E1C: China model
EU: U.S.A. model (AVR-981) E1H: Hong Kong model
E2: Europe model EUT: Taiwan R.O.C. model
E1: Asia model
1 1U-3232S Power unit ass'y for E3,EU 1
1U-3232W for E2 1
1U-3232V for E1,E1H 1
1U-3232X for E1C 1
1U-3232Y for EUT 1
1-1 Power unit
1-2 C.video unit
2 1U-3233S EXT.IN unit ass'y for E3,EU 1
1U-3233W for E2 1
1U-3233V for E1,E1C,E1H 1
1U-3233Y for EUT 1
2-1 EXT IN vr unit
2-2 Display unit
2-3 VOL unit
2-4 P. SW unit
3 1U-3321 Control unit ass'y for E3,EU 1
1U-3321B for E2 1
1U-3321A for E1,E1H 1
1U-3321D for E1C,EUT 1
3-1 Control unit
3-2 Connect unit
3-3 PRE OUT unit
3-4 Digital input unit
3-5 Digital IN-2 unit
4 1U-3235S Regulator unit ass'y for E3,EU 1
1U-3235W for E2 1
1U-3235V for E1,E1H 1
1U-3235X for E1C 1
1U-3235Y for EUT 1
4-1 Regulator unit
4-2 Amp unit
4-3 H/P & P. SW unit
4-4 Front unit
4-5 Tuner unit
4-6 S-video unit
5 1U-3323 Audio/DSP unit ass'y for E3,EU 1
1U-3323A for E1,E1C,E1H 1
1U-3323B for E2 1
1U-3323E for EUT 1
7 1U-3236 Voltage SEL unit ass'y for E1,E1H 1
11 411 1372 526 Main chassis 1
13 412 4210 002 Bracket 1
14 104 0194 289 Foot ass'y 4
15 449 0133 017 PWB holder 1
17 206 2160 009 AC cord VH N/I E3 for E3,EU,EUT 1
17 206 2089 106 AC cord W/CON.E2 for E2 1
17 206 2175 007 AC cord(E1/VH) for E1 1
17 206 2174 008 AC cord(E1C/VH) for E1C 1
17 206 2177 005 AC cord(EK/VH) for E1H 1
18 412 2814 028 Card spacer (L=10) 10
19 412 2814 031 Card spacer (L=4) 1
20 409 0052 019 Holder (A) 1
21 105 1352 007 Back panel for E3 1
21 105 1352 010 Back panel for EU 1
21 105 1352 036 Back panel for E2 1
21 105 1352 023 Back panel for E1,E1H 1
21 105 1352 049 Back panel for E1C 1
21 105 1352 052 Back panel for EUT 1
22 445 0056 008 Cord bush 1
23 205 1116 006 Terminal ass'y 1
24 146 2214 129 Inner panel for Black model 1
24 146 2214 132 Inner panel for Gold mode 1
26 475 6124 003 12 NUT 1
27
9 NUT 3
28 144 2726 006 Front panel ass'y for E3 1
28 144 2726 051 Front panel ass'y for EU 1
28 144 2726 035 Front panel ass'y for E2 (Black model) 1
28 144 2726 048 Front panel ass'y for E2 (Gold model) 1
28 144 2726 022 Front panel ass'y
for E1,E1C,E1H,EUT
1
32 417 0588 005 Radiator 1
33 273 0389 031 2SC3855 LB(O/P/Y)(Z) 5
34 271 0240 035 2SA1491 LB(O/P/Y)(Z) 5
35 412 4127 001 PWB bracket (B) 2
39 412 2741 007 P.W.B. holder (H=8) 1
40 412 4296 107 Radiator bracket 1
41 233 6296 104 Power trans(MAIN/E3) for E3,EU,EUT 1
41 233 6302 001 Power trans(MAIN)-E2 for E2 1
41 233 6303 000 Power trans(MAIN)-E1 for E1,E1H 1
41 233 6318 008 Power trans-MAIN-220V for E1C 1
42 112 0844 006 Knob (M) ass'y for Black model 1
42 112 0844 019 Knob (M) ass'y for Gold mode 1
43 112 0846 004 Knob (F) ass'y for Black model 1
43 112 0846 017 Knob (F) ass'y for Gold mode 1
44 112 0848 002 Knob (S) ass'y for Black model 1
44 112 0848 015 Knob (S) ass'y for Gold mode 1
45 113 1873 105 Push knob for Black model 1
45 113 1873 118 Push knob for Gold mode 1
46 102 0638 008 Top cover for Black model 1
46 102 0638 011 Top cover for Gold mode 1
47
Insulating sheet 10
48 513 3336 002 Caution label for E3,EU 1
49 412 2955 107 Side bracket for E2,E1,E1C,E1H 1
50 203 3981 000 AC outlet (E2) for E2,E1,E1H 1
51 412 4556 009 Earth plate (B) 1
52 412 4557 105 Earth plate (A) 1
53 513 3517 009 Rating label (China) for E1C 1
53 513 3548 007 Rating label (T) for EUT 1
54 146 2151 004 Blind sheet for Gold mode 1
55 203 4871 067 3P KR-KR RIBBON 175 CN031 1
56 203 4871 038 3P KR-KR RIBBON 100 CN037 for E3,EU 1
57 445 8004 007 Wire clamper for E3,EU,E2(Black 3
model),E1C
for E2(Gold model), 4
E1,E1H,EUT
58 477 0096 007 Push rivet for E2,E1,E1C,E1H 14
59 515 8030 066 Preset label for E1,E1H 1
60 513 3518 008 Caution label (E1C) for E1C 1
60 513 2482 009 Caution label (T) for EUT 1
