44
AVR-2801/981
Ref. No. Part No. Part Name Remarks Q'ty Ref. No. Part No. Part Name Remarks
1U-3232 POWER UNIT ASS'Y
OTHER PARTS GROUP
CW051 205 0885 008 5P connector socket (TUC-P) 1
CW061,062 205 0942 019 6P connector socket (TUC-P) 2
CW071,072 205 0942 022 7P connector socket (TUC-P) 2
CW082 205 0885 095 8P connector socket (TUC-P) 1
CW111 205 0885 066 11P connector socket (TUC-P) 1
CW141 205 0885 011 14P connector socket (TUC-P) 1
FB302~308 235 0130 903 Chip emifil (11A121) 7
FB701,702 235 0049 900 Beads inductor 2
FB704~714 235 0049 900 Beads inductor 11
FB800,801 235 0049 900 Beads inductor 2
FB803,804 235 0049 900 Beads inductor 2
FB807~813 235 0049 900 Beads inductor 7
FB815 235 0130 903 Chip emifil (11A121) 1
FB816 235 0049 900 Beads inductor 1
FB817 235 0130 903 Chip emifil (11A121) 1
JK106~108 204 8513 010 6P pin jack (S-GND) 3
L801 235 0130 903 Chip emifil (11A121) 1
L803~805 235 0130 903 Chip emifil (11A121) 3
X302 399 0532 902 Ceramic 12.5 MHz 1
XL802 399 0575 008 Crystal 12.287 MHz 1
SEMICONDUCTORS GROUP
IC401 262 2692 001 IC BU4052BC
IC402 263 0856 004 IC BA7625
IC403 262 2693 000 IC BU4053BC
IC450 263 0856 004 IC BA7625
IC501 268 0073 905 IC ICP-N15
IC502 263 0793 002 IC NJM7806FA(S)
TR401~404 271 0290 904 Transistor 2PA1015GR
TR507,508 273 0454 908 Transistor 2SC1645S(B)
TR511,512 274 0158 016 Transistor 2SD1763A(E)
TR513,514 272 0115 011 Transistor 2SB1186A(E)
TR519,520 273 0458 904 Transistor 2SC3200(BL)
TR527,528 273 0454 908 Transistor 2SC1645S(B)
TR531,532 274 0158 016 Transistor 2SD1763A(E)
TR533,534 272 0115 011 Transistor 2SB1186A(E)
TR539,540 273 0458 904 Transistor 2SC3200(BL)
TR544 273 0454 908 Transistor 2SC1645S(B)
TR546 274 0158 016 Transistor 2SD1763A(E)
TR547 272 0115 011 Transistor 2SB1186A(E)
TR550 273 0458 904 Transistor 2SC3200(BL)
TR551 271 0131 924 Transistor 2SA988(E/F)
TR554 273 0429 904 Transistor 2SC3311A
TR555 271 0192 905 Transistor 2SA933S(S)
TR556,557 273 0429 904 Transistor 2SC3311A
TR558 271 0192 905 Transistor 2SA933S(S)
TR559~566 273 0429 904 Transistor 2SC3311A
D401~404 276 0432 903 Diode 1SS270A
D501~505 276 0432 903 Diode 1SS270A
D507~512 276 0704 903 Diode 1SR35-400A
D513~517 276 0432 903 Diode 1SS270A
D518,519 276 0305 001 Diode S4VB20
D520 276 0432 903 Diode 1SS270A
D526~535 276 0432 903 Diode 1SS270A
ZD501 276 0644 911 Zener diode MTZJ7.5A
ZD502~511 276 0634 905 Zener diode MTZJ3.3A
SC501 279 0016 904 Thyristor SF0R1A42
RESISTORS GROUP
R525~528 244 2052 957 Metal oxide 5.6 kohm 1W
RS14B3A562JNBS(S)
R537,538 241 2378 962
Carbon film 330 ohm 1/4W(NB)
RD14B2E331JNBS
R539~542 241 2387 908 Carbon film 1 ohm 1/4W(NB) RD14B2E010JNBS
R543~550 244 2043 982 Metal oxide 0.22 ohm 1W
RS14B3AR22JNBS(S)
R551,552 241 2379 987 Carbon film 1 kohm 1/4W(NB) RD14B2E102JNBS
R557,558 244 2043 937 Metal oxide 10 ohm 1W
RS14B3A100JNBS(S)
R567,568 244 2043 937 Metal oxide 10 ohm 1W
RS14B3A100JNBS(S)
R571 244 2043 937 Metal oxide 10 ohm 1W
RS14B3A100JNBS(S)
