Denon AVR-2801/981 - Page 27

27
AVR-2801/981

OTHERS
GP1U271X (Remote Control Sensor)
(EX: IC102)
GND
Vcc
Vout
H ead
Am p
Lim iter
Am p
BPF
D e te c to r &
C om parator
Integrator
H ysteresis
C om parator
Output
GND
Input
NJM7912FA (RE: IC907)
Output
Input
GND
4
V
DD
1
2
OE
Vss
OUT
1
2
4
3

IC PROTECTOR
ICP-N15 (PO: IC501)

OPTICAL
INPUT
GP1F37R1 (CO: IC701~703)
1
2
3
1
3
2
1. Vcc
2. GND
3. Vout
NJM7805FA (S) (RE: IC902, 903)
NJM7806FA (S)
(PO: IC502)
(RE: IC904)
NJM7812FA (S) (RE: IC906)
BA033T (AU: 819)
NJM7912FA (RE: IC907)
SG-8002DCPT (12.287MHz)
(AU: XL802)
V
1
2
4
3
3
1. Vcc
2. GND
3. Vout
GND
V
OUT
Vcc
SN74AHCT1G08DBV (AU: IC821)
1
2
3
4
5
1: A
2: B
3: GND
4: Y
5: Vcc
1
2
4
