(5) Disconnecttheconnectorwire,thenremovethescrewsandtheSUPPORTERP.C..
(6) RemovetheLICENCELABEL,thenremovethescrewsandSUPPORTERP.C..
RemovetheHDMIUNITASSYfromthemainunit.
Pleasereferto"EXPLODEDVIEW"forthedisassemblymethodofeachP.W.BincludedinHDMIUNITASSY.
5. TRANS MAIN
Pleasereferto"EXPLODEDVIEW"forthedisassemblymethodofeachP.W.BincludedinTRANSMAIN.
CX102
SUPPORTER P.C.
View from bottom
SUPPORTER P.C.
LICENCE LABEL
CABINET TOP
TRANS MAIN
→
Proceeding :
HDMI UNIT ASSY
→
