Denon AVR-3311CI Service Manual

197
PCB REG_CNT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC1 00D2631289900 IC AZ4580M-TRE1-SOIC8P E3 J121458000020S
IC103 00D2630809006 IC NJM7805FA J126780500130S
IC104 00D2630554005 IC NJM7905FA J126790500020S
IC105 00D2630809006 IC NJM7805FA J126780500130S
IC106 00D2630810008 IC NJM7808FA J126780800030S
IC107 00D2630503001 IC NJM7908FA J126790800020S
IC108 963239010770S IC NJM2388F09 E2, E1C J126238800090S
IC109 nsp IC PQ033DNA1ZPH E3 J126033010010S
IC402 00D2631289900 IC AZ4580M-TRE1-SOIC8P E3 J121458000020S
IC404 963239008800S IC ILX3232D J046323200020S
IC405,406 nsp IC PQ120DNA1ZPH J126120010010S
D114 00D9630236504 D, SHOTTKY RB721Q K120072140010S
D115,116 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D117,118 00D9630236504 D, SHOTTKY RB721Q K120072140010S
D119-121 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D122 00D9630236504 D, SHOTTKY RB721Q K120072140010S
D123 00D2760401905 D,SWITCHING 1SS133T E2, E1C K000013300520S
D124-134 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D137-145 00D9630328409 D,SWITCHING 1N4007 K000400700010S
ZD117,118 00D9600096004 D,ZENER MTZJ33B K06033R044520S
ZD401,402 00D2760665903 D,ZENER MTZJ16B K06016R044520S
CAPACITORS GROUP
C61 nsp C, CERAMIC 33PF-J/50V E3 D010330167160S
C62,63 00D9630234205 C,ELECT 10UF-M/50V E3 D040100087070S
C64 nsp C, CERAMIC 33PF-J/50V E3 D010330167160S
C65 nsp C, CERAMIC 0.1UF-K/50V E3 D011104577160S
C66 nsp C, CERAMIC 1UF-K/16V E3 D011105173161S
C67 nsp C, CERAMIC 33PF-J/50V E3 D010330167160S
C68-70 00D9630234205 C,ELECT 10UF-M/50V E3 D040100087070S
C71 nsp C, CERAMIC 0.1UF-K/50V E3 D011104777200S
C72 nsp C, CERAMIC 33PF-J/50V E3 D010330167160S
C73 nsp C, CERAMIC 1UF-K/16V E3 D011105173161S
C74 nsp C, CERAMIC 0.1UF-K/50V E3 D011104577160S
C75 00D9630234205 C,ELECT 10UF-M/50V E3 D040100087070S
C76-78 nsp C, CERAMIC 100PF-J/50V E3 D010101167160S
C79 nsp C, CERAMIC 0.1UF-K/50V E3 D011104577160S
C80,81 00D9630234205 C,ELECT 10UF-M/50V E3 D040100087070S
C126 00D9630217002 C,ELECT 3300UF-M/16V D040332083010S
C127,128 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C129 00D9630217002 C,ELECT 3300UF-M/16V D040332083010S
C130 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C131 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C132 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C133 90M-OA000500R C,ELECT 4700UF-M/25V(MHA) D040472084240S
C134 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C135 90M-OA000500R C,ELECT 4700UF-M/25V(MHA) D040472084240S
C136 00D9630333203 C,ELECT 100UF-M/16V E2, E1C D040101083090S
C137 00D9630234205 C,ELECT 10UF-M/50V E2, E1C D040100087070S
C138 90M-OA000500R C,ELECT 4700UF-M/25V(MHA) D040472084240S
C142-144 nsp C,FILM 0.1UF-J/50V D020104167050S
C146-148 nsp C,FILM 0.1UF-J/50V D020104167050S
C403, 404 nsp C, CERAMIC 0.1UF-K/50V E3 D011104577160S
C407,408 963134010940S C,ELECT 10UF-M/16V E3 D040100083090S
C427 nsp C, CERAMIC 0.1UF-K/50V E3 D011104577160S
C432-435 00D9630234205 C,ELECT 10UF-M/50V E3 D040100087070S
C439, 440 nsp C, CERAMIC 470PF-K/50V E3 D011471767160S
C443 nsp C, CERAMIC 470PF-K/50V E3 D011471767160S
C444 nsp C, CERAMIC 0.1UF-K/50V E3 D011104577160S
C448-451 nsp C, CERAMIC 0.1UF-K/50V D011104577160S
C452 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
