Denon AVR-3311CI Service Manual

182
LAN8700PinDescription
±15kV ESD Protected MII/RMII Fast-Ethernet PHY with HP Auto-MDIX and SMSC flexPWR
TM
in a Small Footprint
Datasheet
SMSC LAN8700/LAN8700I 11 Revision 1.0 (02-09-07)
DATASHEET
Table 2.1 LAN8700/LAN8700I 36-PIN QFN Pinout
PIN NO. PIN NAME PIN NO. PIN NAME
1 nINT/TX_ER/TXD4 19 RX_DV
2 MDC 20 RX_CLK/REGOFF
3 CRS/PHYAD4 21 RX_ER/RXD4
4 MDIO 22 TXCLK
5 nRST 23 TXD0
6 TX_EN 24 TXD1
7 VDD33 25 VDDIO
8 VDD_CORE 26 TXD2
9 SPEED100/PHYAD0 27 TXD3
10 LINK/PHYAD1 28 TXN
11 ACTIVITY/PHYAD2 29 TXP
12 FDUPLEX/PHYAD3 30 VDDA3.3
13 XTAL2 31 RXN
14 CLKIN/XTAL1 32 RXP
15 RXD3/nINTSEL 33 VDDA3.3
16 RXD2/MODE2 34 EXRES1
17 RXD1/MODE1 35 VDDA3.3
18 RXD0/MODE0 36 COL/RMII/CRS_DV
