Denon AVR-3311CI Service Manual

204
PCB AUDIO ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC3000 00D2631289900 IC AZ4580M J121458000020S
IC3003 235810045600S IC R2A15220FP J084152200010S *
IC3005,3006 00D2631289900 IC AZ4580M J121458000020S
IC3007 00D2623727904 IC NJW1194A J084119400010S
IC3008-3010 00D2631289900 IC AZ4580M J121458000020S
IC3011 00D2623727904 IC NJW1194A J084119400010S
IC3012 00D2631289900 IC AZ4580M J121458000020S
Q4001 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q4002,4003 00D9630120704 TR KRA102S(PB) J520010200210S
Q4005 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q4006 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q4008 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q4009,4010 00D9630120704 TR KRA102S(PB) J520010200210S
Q4012 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q4013 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q4015 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q4016,4017 00D9630120704 TR KRA102S(PB) J520010200210S
Q4019 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q4020,4021 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q4023 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q4024-4027 00D9630120704 TR KRA102S(PB) J520010200210S
Q4029 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q4030 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q4032 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q4033,4034 00D9630120704 TR KRA102S(PB) J520010200210S
Q4036 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q4037 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q4039 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q4040,4041 00D9630120704 TR KRA102S(PB) J520010200210S
Q4043 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q4044,4045 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q4047 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q4048,4049 00D9630120704 TR KRA102S(PB) J520010200210S
Q4098,4099 963219010760S TR KRC231(NW) E2, E1C J5220231M0010S
Q4100 00D9630120801 TR 2SC KRC102S (NB) E2, E1C J522010200210S
Q4101 963219010740S TR KRA111S E2, E1C J520011100210S
Q4102 00D9630120801 TR 2SC KRC102S (NB) E2, E1C J522010200210S
D3023 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D3025 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D4000-4002 00D9630328409 D,SWITCHING 1N4007 K000400700010S
ZD4000 00D2760693962 D,ZENER 0.2W 3.6V UDZ K06603R64P400S
CAPACITORS GROUP
C3000 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C3001,3002 00D9630234205 C,ELECT 10UF-M/50V E3,E1C D040100087070S
C3001,3002 00D2544583900 C,ELECT 10UF-M/50V (ROB) E2 D040100087140S
C3003-3008 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C3011-3017 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C3018 nsp C,CERAMIC 100PF-J/50V D010101167160S
C3019 963134010960S C,ELECT 220UF-M/10V D040221082080S
C3021 nsp C,CERAMIC 220PF-J/50V D010221167160S
C3022 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C3023 nsp C,FILM 0.022UF-J/100V D02022306C060S
C3024 nsp C,FILM 0.0068UF-J/100V D02068206C060S
C3027 nsp C,FILM 0.022UF-J/100V D02022306C060S
C3028 nsp C,FILM 0.0068UF-J/100V D02068206C060S
C3029 nsp C,CERAMIC 220PF-J/50V D010221167160S
C3030 963134010960S C,ELECT 220UF-M/10V D040221082080S
C3031 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C3033 nsp C,CERAMIC 100PF-J/50V D010101167160S
