Denon AVR-3312 Service Manual

164
Ref. No. Part No. Part Name Remarks Q'ty New
C21 nsp PCB SMPS ASSY E3 COP12391B 1 *
C21 nsp PCB SMPS ASSY E2 COP12391C 1 *
C21 nsp PCB SMPS ASSY E1C COP12391D 1 *
5 8U6331007800D PCB HDMI ASSY E3 COP12390B 1 *
5 8U6331007900D PCB HDMI ASSY E2 COP12390C 1 *
5 8U6331010800D PCB HDMI ASSY E1C COP12390D 1 *
C22 - PCB HDMI -
C25 - PCB FRONT HDMI -
z
C23 943101012430S TRANS , POWER(EI96 X 75) E3 CLT5V060ZU 1 *
z
C23 943101012440S TRANS , POWER(EI96 X 75) E2 CLT5V060ZE 1 *
z
C23 943101100200S TRANS , POWER(EI96 X 75) E1C CLT5V060ZH 1 *
C24 963183011000S MODULE , HD-RADIO E3
CNVKSM-
H7101NNH-001
1
C26 nsp TERMINAL,GROUND CMA1A006 1
P1 943419100300D COVER, RCA BK CGR1A517B28 1 *
P1 943419100310D COVER, RCA SP CGR1A517G45 1 *
P2 943412009840D VOLUME KNOB BK CBN1A249 1
P2 943412009850D VOLUME KNOB SP CBN1A249C73 1
P3 943402101780D PANEL, FRONT CIBKE3 CGW1A511RHWB28 1 *
P3 943402101800D PANEL, FRONT BKE2
CGW1A511RHVB28 1 *
P3 943402101820D
PANEL, FRONT SPE1C CGW1A511RGUG45 1 *
P4 943412100650D KNOB , SELECT BK CBN1A254 1 *
P4 943412100640D KNOB , SELECT SP CBN1A254C73 1 *
P5 00D9630362109 DENON BADGE(BLACK049) CGB1A140U 1
P6 943411101430D BUTTON, 3KEY ASSY BK CBT1A1157ZA 1 *
P6 943411101480D BUTTON, 3KEY ASSY SP CBT1A1157G45Z 1 *
P7 943411009860D BUTTON STANDBY ASS'Y CBT1A1141ZA 1
P8 00D9630137807 STANDBY LENS CGL1A289 1
P9 943411101440D BUTTON, 5KEY ASS'Y BK CBT1A1156ZA 1 *
P9 943411101490D BUTTON, 5KEY ASS'Y SP CBT1A1156G45Z 1 *
P10 00D9630365002 WIN 3KEY BUTTON BK CBT1A1140B28 2
P10 00D9630365301 WIN 3KEY BUTTON
SP CBT1A1140G45 2
P11 943411101450D BUTTON , WIN 3KEY B
BK CBT1A1160B28 1 *
P11 943411101720D BUTTON , WIN 3KEY B
SP CBT1A1160G45 1 *
P12 943416009700D FOOT CKL2A093 4
*
P13 00D9430202902 FOOT CUSHION CHG2A289 4
P14 nsp HOLDER , PCB CHE170 5 *
P15 nsp SUPPORT, PCB CRE1A102 1 *
P16 nsp SUPPORT , PCB 31 CRE1A073 1 *
P17 nsp RUBBER CHG1A113 4 *
P18 943416100580D WINDOW, FL CGU1A459X 1 *
P19 943419100250D CGX1A492Z SHEET TOP AVR1612BK BKE2 CGX1A492Z
2
P19 943419100260D CGX1A492Y SHEET TOP AVR1612SP E1C CGX1A492Y 2
P20 45451000500AM STOPPER TOP BL BKE2 CMH1A306Z 8
P20 45451000501AM STOPPER TOP SG E1C CMH1A306Y 8
g
f

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
