Denon AVR-3312 Service Manual

165
Ref. No. Part No. Part Name Remarks Q'ty New
M1 nsp EARTH , AUX CMC1A421 1 *
M2 nsp EARTH , USB CMC1A423 1 *
M3 nsp EARTH , USB CMC1A420 1 *
M4 nsp HEAT SINK CMY1A376 1 *
M5 nsp BRACKET , AMP PCB CMD1A796 5 *
M6 nsp BOTTOM, CHASSIS CUA1A330 1 *
M7 nsp PLATE , MAIN PCB CMC1A424 1 *
M8 nsp SMPS BRACKET CMD1A790 1 *
M9 nsp BRACKET PCB HDMI CMD1A791 1 *
M10 nsp PANEL , REAR E3 CKF6A448Z 1 *
M10 nsp PANEL , REAR E2 CKF7A448Z 1 *
M10 nsp PANEL , REAR E1C CKF7A448Y 1 *
M11 00M07BW257010 TOP CABINET BK CKC2A155K117 1
M11 943403002040M TOP CABINET SP CKC2A155D11 1
★
M12 nsp CLAMPER CHR301 10
★
M13 nsp CLAMPER ARM CHE154 0.12
★
M14 nsp CUSHION, EVA CHG1A518 1 *
★
M15 nsp INSULATOR , SILICON CMX1A298 14 *
★
M16 nsp LABEL , HOT CQB1A906Z 1
★
M17 nsp TAPE , BOTH SIDE 0.05mm C4FM073 1 *
★
M18 nsp TAPE , HEMELON 10mm CHS1A032 1
★
M19 nsp TAPE , HEMELON 10mm CHS1A032 1
SCREWS
S1 nsp SCREW , SPECIAL CHD3A012R 21
S2 nsp SCREW CTWS3+10GR 1
S4 nsp SCREW CTB3+10JR 25
S5 nsp SCREW CTBD3+8JFZR 3
S5 nsp SCREW CTBD3+8JFZR 42
S7 nsp SCREW CTBD3+6FFZR 12
S8 nsp SCREW CTW3+8JR 17
S9 nsp SCREW CTW3+12JR 5
S10 nsp SCREW , SPECIAL CHD1A023R 4
S11 nsp SCREW CTB3+8JR 10
S11 nsp SCREW CTB3+8JR 18
S13 nsp SCREW CTBD4+8JFZR 6
S14 nsp SCREW CTB3+8JFZR 7
WIRES
★
W1
943606501240S CARD CABLE (1mm, 40P, 250mm, B) CWC4F2A40A250B08 1
★
W2 943606501250S CARD CABLE (1mm, 23P, 450mm, B) CWC4F2A23A450B10 1
★
W3 943606501260S CARD CABLE (1.25mm, 13P, 80mm, B) E3 CWC4F2A13B080B10 1

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
