Denon AVR-3312 Service Manual

204
Ref. No. Part No. Part Name Remarks Q'ty New
D7011,7012 943209001080S
DIODE 1SS355T CVD1SS355T
D7108,7109 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7115,7116 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7118 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7139 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7208,7209 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7215,7216 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7218 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7239 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7308,7309 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7315,7316 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7318 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7339 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7408,7409 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7415,7416 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7418 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7439 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7508,7509 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7515,7516 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7518 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7539 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7608,7609 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7615,7616 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7618 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7639 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7708,7709 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7715,7716 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7718 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7739 00D9430182609 DIODE 1SS133MT CVD1SS133MT
RESISTORS GROUP
z
R7012 252310006520S
PTC THEMISTORS, CHIP(95'C) CRTPRF18BD471QB5RB
z
R7014 252310006520S
PTC THEMISTORS, CHIP(95'C) CRTPRF18BD471QB5RB
R7105 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT
R7108 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT
R7111 nsp RES, M-OXIDE FILM(1W/3.3Kohm) CRG1SANJ332RT
R7114 nsp RES, M-OXIDE FILM(1W/56Kohm) CRG1SANJ563RT
R7118,7119 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT
R7120 nsp RES, M-OXIDE FILM(2W/15Kohm) CRG2SANJ153RT
R7121 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT
R7129,7130 943124500240S RES, M-OXIDE FILM(1W/22ohm) FLAMERETARDANT CRG1SANJ220RT *
R7131-7134 943124500050S
RES,M-OXIDEFILM(2W/0.47ohm) FLAMERETARDANT CRG2SANJR47RT
z
R7138 252310006506S PTC THEMISTORS, CHIP(115'C) CRTPRF18BB471QB5RB
R7205 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT
R7208 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT
R7211 nsp RES, M-OXIDE FILM(1W/3.3Kohm) CRG1SANJ332RT
R7214 knsp RES, M-OXIDE FILM(1W/56Kohm) CRG1SANJ563RT
R7218,7219 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT
R7220 nsp RES, M-OXIDE FILM(2W/15Kohm) CRG2SANJ153RT
R7221 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT
R7230 943124500240S RES, M-OXIDE FILM(1W/22ohm) FLAMERETARDANT CRG1SANJ220RT *
R7231-7234 943124500050S
RES,M-OXIDEFILM(2W/0.47ohm) FLAMERETARDANT CRG2SANJR47RT
z
R7238 252310006506S PTC THEMISTORS, CHIP(115'C) CRTPRF18BB471QB5RB
R7279 943124500240S RES, M-OXIDE FILM(1W/22ohm) FLAMERETARDANT CRG1SANJ220RT *
R7305 nsp
RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT
R7308 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT
R7311 nsp RES, M-OXIDE FILM(1W/3.3Kohm) CRG1SANJ332RT
R7314 nsp RES, M-OXIDE FILM(1W/56Kohm) CRG1SANJ563RT
R7318,7319 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT
R7320 nsp RES, M-OXIDE FILM(2W/15Kohm) CRG2SANJ153RT
R7321 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT
R7329,7330 943124500240S RES, M-OXIDE FILM(1W/22ohm) FLAMERETARDANT CRG1SANJ220RT *
R7331-7334 943124500050S
RES,M-OXIDEFILM(2W/0.47ohm) FLAMERETARDANT CRG2SANJR47RT
z
R7338 252310006506S PTC THEMISTORS, CHIP(115'C) CRTPRF18BB471QB5RB
R7405 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT
R7408 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
