Denon AVR-3312 Service Manual

205
Ref. No. Part No. Part Name Remarks Q'ty New
R7411 nsp
RES, M-OXIDE FILM(1W/3.3Kohm) CRG1SANJ332RT
R7414 nsp RES, M-OXIDE FILM(1W/56Kohm) CRG1SANJ563RT
R7418,7419 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT
R7420 nsp RES, M-OXIDE FILM(2W/15Kohm) CRG2SANJ153RT
R7421 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT
R7429,7430 943124500240S RES, M-OXIDE FILM(1W/22ohm) FLAMERETARDANT CRG1SANJ220RT *
R7431-7434 943124500050S
RES,M-OXIDEFILM(2W/0.47ohm) FLAMERETARDANT CRG2SANJR47RT
z
R7438 252310006506S
PTC THEMISTORS, CHIP(115'C) CRTPRF18BB471QB5RB
R7505 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT
R7508 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT
R7511 nsp RES, M-OXIDE FILM(1W/3.3Kohm) CRG1SANJ332RT
R7514 nsp RES, M-OXIDE FILM(1W/56Kohm) CRG1SANJ563RT
R7518,7519 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT
R7520 nsp RES, M-OXIDE FILM(2W/15Kohm) CRG2SANJ153RT
R7521 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT
R7529,7530 943124500240S RES, M-OXIDE FILM(1W/22ohm) FLAMERETARDANT CRG1SANJ220RT *
R7531-7534 943124500050S
RES,M-OXIDEFILM(2W/0.47ohm) FLAMERETARDANT CRG2SANJR47RT
z
R7538 252310006506S
PTC THEMISTORS, CHIP(115'C) CRTPRF18BB471QB5RB
R7605 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT
R7608 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT
R7611 nsp RES, M-OXIDE FILM(1W/3.3Kohm) CRG1SANJ332RT
R7614 nsp RES, M-OXIDE FILM(1W/56Kohm) CRG1SANJ563RT
R7618,7619 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT
R7620 nsp RES, M-OXIDE FILM(2W/15Kohm) CRG2SANJ153RT
R7621 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT
R7629,7630 943124500240S RES, M-OXIDE FILM(1W/22ohm) FLAMERETARDANT CRG1SANJ220RT *
R7631-7634 943124500050S
RES,M-OXIDEFILM(2W/0.47ohm) FLAMERETARDANT CRG2SANJR47RT
z
R7638 252310006506S PTC THEMISTORS, CHIP(115'C) CRTPRF18BB471QB5RB
R7705 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT
R7708 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT
R7711 nsp RES, M-OXIDE FILM(1W/3.3Kohm) CRG1SANJ332RT
R7714 nsp RES, M-OXIDE FILM(1W/56Kohm) CRG1SANJ563RT
R7718,7719 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT
R7720 nsp RES, M-OXIDE FILM(2W/15Kohm) CRG2SANJ153RT
R7721 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT
R7729,7730 943124500240S RES, M-OXIDE FILM(1W/22ohm) FLAMERETARDANT CRG1SANJ220RT *
R7731-7734 943124500050S
RES,M-OXIDEFILM(2W/0.47ohm) FLAMERETARDANT CRG2SANJR47RT
z
R7738 252310006506S
PTC THEMISTORS, CHIP(115'C) CRTPRF18BB471QB5RB
VR714 963161012400S RES ,SEMI FIXED(1K/B-CURVE) ANGLE CVN1RE102B01T
VR724 963161012400S RES ,SEMI FIXED(1K/B-CURVE) ANGLE CVN1RE102B01T
VR734 963161012400S RES ,SEMI FIXED(1K/B-CURVE) ANGLE CVN1RE102B01T
VR744 963161012400S RES ,SEMI FIXED(1K/B-CURVE) ANGLE CVN1RE102B01T
VR754 963161012400S RES ,SEMI FIXED(1K/B-CURVE) ANGLE CVN1RE102B01T
VR764 963161012400S RES ,SEMI FIXED(1K/B-CURVE) ANGLE CVN1RE102B01T
VR774 963161012400S RES ,SEMI FIXED(1K/B-CURVE) ANGLE CVN1RE102B01T
CAPACITORS GROUP
C7001 nsp
CHIP CAP 0.01UF 50V K CCUS1H103KC
C7011,7012 943134501570S CAP , ELECT(10V/330uF) CCEA1AH331T *
C7013 00D9630324607
CAP , ELECT(10V/47uF) CCEA1AH470T
C7101 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C7102 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C7104 nsp CHIP CAP 220PF 50V CCUS1H221JA
C7105 nsp CAP, CHIP(1608, 50V/2200pF) CCUS1H222KC
C7106 00MOA10705020 ELECT CAP 100UF 50V CCEA1HH101T
C7112 nsp CAP, PE-FILM(100V/220pF/J) SEORYONG CCME2A221JR11T
C7120 nsp CAP, PE-FILM(100V/220pF/J) SEORYONG CCME2A221JR11T
C7121 nsp CAP, PE-FILM(100V/470pF/J) SEORYONG CCME2A471JR11T
C7125 00D9430148708 ELECT CAP 47UF 50V E3,E1C CCEA1HH470T
C7125 943134500080S ELECT CAP 47UF 63V E2 CCEA1JH470T
C7131,7132 943134500070S CAP , ELECT(100V/10uF) CCEA2AH100TS
C7138 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C7201 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C7202 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C7204 nsp CHIP CAP 220PF 50V CCUS1H221JA

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
