Denon AVR-3312 Service Manual

206
Ref. No. Part No. Part Name Remarks Q'ty New
C7205 nsp
CAP, CHIP(1608, 50V/2200pF) CCUS1H222KC
C7206 00MOA10705020 ELECT CAP 100UF 50V CCEA1HH101T
C7212 nsp CAP, PE-FILM(100V/220pF/J) SEORYONG CCME2A221JR11T
C7220 nsp CAP, PE-FILM(100V/220pF/J) SEORYONG CCME2A221JR11T
C7221 nsp CAP, PE-FILM(100V/470pF/J) SEORYONG CCME2A471JR11T
C7225 00D9430148708 ELECT CAP 47UF 50V E3,E1C CCEA1HH470T
C7225 943134500080S ELECT CAP 47UF 63V E2 CCEA1JH470T
C7231,7232 943134500070S ELECT CAP 10UF 100V E3,E1C CCEA2AH100TS
C7238 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C7301 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C7302 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C7304 nsp CHIP CAP 220PF 50V CCUS1H221JA
C7305 nsp CAP, CHIP(1608, 50V/2200pF) CCUS1H222KC
C7306 00MOA10705020 ELECT CAP 100UF 50V CCEA1HH101T
C7312 nsp CAP, PE-FILM(100V/220pF/J) SEORYONG CCME2A221JR11T
C7320 nsp CAP, PE-FILM(100V/220pF/J) SEORYONG CCME2A221JR11T
C7321 nsp CAP, PE-FILM(100V/470pF/J) SEORYONG CCME2A471JR11T
C7325 00D9430148708 ELECT CAP 47UF 50V E3,E1C CCEA1HH470T
C7325 943134500080S ELECT CAP 47UF 63V E2 CCEA1JH470T
C7331,7332 943134500070S CAP , ELECT(100V/10uF) E3,E1C CCEA2AH100TS
C7338 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C7401 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C7402 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C7404 nsp CHIP CAP 220PF 50V CCUS1H221JA
C7405 nsp CAP, CHIP(1608, 50V/2200pF) CCUS1H222KC
C7406 00MOA10705020 ELECT CAP 100UF 50V CCEA1HH101T
C7412 nsp CAP, PE-FILM(100V/220pF/J) SEORYONG CCME2A221JR11T
C7420 nsp CAP, PE-FILM(100V/220pF/J) SEORYONG CCME2A221JR11T
C7421 nsp CAP, PE-FILM(100V/470pF/J) SEORYONG CCME2A471JR11T
C7425 00D9430148708 ELECT CAP 47UF 50V E3,E1C CCEA1HH470T
C7425 943134500080S ELECT CAP 47UF 63V E2 CCEA1JH470T
C7431,7432 943134500070S CAP , ELECT(100V/10uF) E3,E1C CCEA2AH100TS
C7438 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C7501 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C7502 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C7504 nsp CHIP CAP 220PF 50V CCUS1H221JA
C7505 nsp CAP, CHIP(1608, 50V/2200pF) CCUS1H222KC
C7506 00MOA10705020 ELECT CAP 100UF 50V CCEA1HH101T
C7512 nsp CAP, PE-FILM(100V/220pF/J) SEORYONG CCME2A221JR11T
C7520 nsp CAP, PE-FILM(100V/220pF/J) SEORYONG CCME2A221JR11T
C7521 nsp CAP, PE-FILM(100V/470pF/J) SEORYONG CCME2A471JR11T
C7525 00D9430148708 ELECT CAP 47UF 50V E3,E1C CCEA1HH470T
C7525 943134500080S ELECT CAP 47UF 63V E2 CCEA1JH470T
C7531,7532 943134500070S CAP , ELECT(100V/10uF) CCEA2AH100TS
C7538 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C7601 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C7602 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C7604 nsp CHIP CAP 220PF 50V CCUS1H221JA
C7605 nsp CAP, CHIP(1608, 50V/2200pF) CCUS1H222KC
C7606 00MOA10705020 ELECT CAP 100UF 50V CCEA1HH101T
C7612 nsp CAP, PE-FILM(100V/220pF/J) SEORYONG CCME2A221JR11T
C7620 nsp CAP, PE-FILM(100V/220pF/J) SEORYONG CCME2A221JR11T
C7621 nsp CAP, PE-FILM(100V/470pF/J) SEORYONG CCME2A471JR11T
C7625 00D9430148708 ELECT CAP 47UF 50V E3,E1C CCEA1HH470T
C7625 943134500080S ELECT CAP 47UF 63V E2 CCEA1JH470T
C7631,7632 943134500070S CAP , ELECT(100V/10uF) E3,E1C CCEA2AH100TS
C7638 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C7701 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C7702 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C7704 nsp CHIP CAP 220PF 50V CCUS1H221JA
C7705 nsp CAP, CHIP(1608, 50V/2200pF) CCUS1H222KC
C7706 00MOA10705020 ELECT CAP 100UF 50V CCEA1HH101T
C7712 nsp CAP, PE-FILM(100V/220pF/J) SEORYONG CCME2A221JR11T
C7720 nsp CAP, PE-FILM(100V/220pF/J) SEORYONG CCME2A221JR11T
C7721 nsp CAP, PE-FILM(100V/470pF/J) SEORYONG CCME2A471JR11T
C7725 00D9430148708 ELECT CAP 47UF 50V E3,E1C CCEA1HH470T
C7725 943134500080S ELECT CAP 47UF 63V E2 CCEA1JH470T

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
