Denon AVR-3312 Service Manual

207
Ref. No. Part No. Part Name Remarks Q'ty New
C7731,7732 943134500070S
CAP , ELECT(100V/10uF) CCEA2AH100TS
C7738 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
OTHERS PARTS GROUP
BK701 nsp
PCB BRACKET CMD1A569
BN704 nsp WIRE ASS'Y (5P,2.0MM,250MM,UL1007#26) CWB1B005250LC
CN461 nsp LOCK-WAFER/STRAIGHT/2MM PITCH/13PIN CJP13GI288ZY
CN701 nsp LOCK-WAFER/STRAIGHT/2.5MM PITCH/9PIN CJP09GI289ZY
CN702 nsp LOCK-WAFER/STRAIGHT/2.5MM PITCH/7PIN CJP07GI289ZY
CN703 nsp LOCK-WAFER/STRAIGHT/2.5MM PITCH/3PIN CJP03GI289ZY
CN715 nsp WAFER (3PIN, AN, 2MM, JWT) CJP03GB48ZW
CN725 nsp WAFER (3PIN, AN, 2MM, JWT) CJP03GB48ZW
CN735 nsp WAFER (3PIN, AN, 2MM, JWT) CJP03GB48ZW
CN745 nsp WAFER (3PIN, AN, 2MM, JWT) CJP03GB48ZW
CN755 nsp WAFER (3PIN, AN, 2MM, JWT) CJP03GB48ZW
CN765 nsp WAFER (3PIN, AN, 2MM, JWT) CJP03GB48ZW
CN775 nsp WAFER (3PIN, AN, 2MM, JWT) CJP03GB48ZW
GND71 nsp EARTH PALTE HJT1A025
ZD714 943202010080S DIODE ZJ5.1B CVDZJ5.1BT
ZD715,716 90M-HD302440R DIODE ZJ4.7B CVDZJ4.7BT
ZD724 943202010080S DIODE ZJ5.1B CVDZJ5.1BT
ZD725,726 90M-HD302440R DIODE ZJ4.7B CVDZJ4.7BT
ZD734 943202010080S DIODE ZJ5.1B CVDZJ5.1BT
ZD735,736 90M-HD302440R DIODE ZJ4.7B CVDZJ4.7BT
ZD744 943202010080S DIODE ZJ5.1B CVDZJ5.1BT
ZD745,746 90M-HD302440R DIODE ZJ4.7B CVDZJ4.7BT
ZD754 943202010080S DIODE ZJ5.1B CVDZJ5.1BT
ZD755,756 90M-HD302440R DIODE ZJ4.7B CVDZJ4.7BT
ZD764 943202010080S DIODE ZJ5.1B CVDZJ5.1BT
ZD765,766 90M-HD302440R DIODE ZJ4.7B CVDZJ4.7BT
ZD774 943202010080S DIODE ZJ5.1B CVDZJ5.1BT
ZD775,776 90M-HD302440R DIODE ZJ4.7B CVDZJ4.7BT

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
