Denon AVR-3312 Service Manual

89
YES
YES
YES
Check TV
(11) Is the TV HDCP-compatible?
(16) Is the set's input set to HDMI?
Is the output setting of set corresponding to the connection of TV?
(13) Is the TV's input set to HDMI?
(14) Are the picture and sound output when a different TV is used?
Check set (AV RECEIVER)
(12) Is the TV compatible with resolutions of 1080P?
Use an HDCP-compatible TV. PC TVs
cannot be used.
Check the set's input setting, referring to the
set's operating instructions.
Check the TV's input setting, referring to the
TV's operating instructions.
The TV is defective.
If the TV is not compatible with resolutions
of 1080P, no picture will be output, even
if the BD/DVD player's resolution is set to
1080P.
NO
NO
NO
NO
NO
YES
YES
The set does not recognize
the TV.
(MONITOR OUT: Set
MONITOR1)
(17) Is the "H"(3V-5V) signal
outputted of TP[HPD] in the
vicinity of JK151?
With the TV
connected,check the
voltage of the IC on the
side on which the TV is
connected.
Is communication
waveform conrmed in
TP[DDC_CLK/DDC_
DATA] in the HDMI
connector (JK151)?
Is D1601/D1602/D1603/
D1604/D1605/D1606/
D1607/D1608 terminated
by the TMDS signal of
3.3V and is the signal
output?
The set does not recognize
the TV.
(MONITOR OUT: Set
MONITOR2)
(32) Is the "H"(3V-5V) signal
outputted of TP[HPD] in the
vicinity of JK152?
With the TV
connected,check the
voltage of the IC on the
side on which the TV is
connected.
Is communication
waveform conrmed in
TP[DDC_CLK/DDC_
DATA] in the HDMI
connector (JK152)?
Is D1613/D1614/D1615/
D1616/D1617/D1618/
D1619/D1620 terminated
by the TMDS signal of
3.3V and is the signal
output?
The pattern and circuit from the HDMI
connector (JK151) to the IC151 is defective,
or HDMI output circuitry is defective (IC151
and surrounding circuitry).
The pattern and circuit from the HDMI
connector (JK151/152) to the IC151 is
defective, or HDMI output circuitry is
defective (IC151 and surrounding circuitry).
NO
YES
NO
(15) Is a contact part of HDMI connector normal?
(Refer to 91 page (*1).)
The HDMI connector is defective.
Replace the new HDMI connector.
NO
YES

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
