Denon AVR-3312 Service Manual

90
YES
YES
YES
(18)
When using a DENON
BD/DVD player, is the FL
display's "HDMI" indicator lit?
If using a non-DENON BD/
DVD player, proceed to "NO".
The BD/DVD player does not recognize the
connection with the set.
(19)
Is the "H"(3V-5V) signal outputted of HDMI
connector (JK101/JK111/JK112/JK113/JK114/
JK121/JK122 : TP[HPD])?
With the BD/DVD player connected, Check
voltage of the HDMI connector for the input on the
side on which the BD/DVD player is connected.
Is communication waveform conrmed in
TP[DDC_CLK]/TP[DDC_DATA] around each
HDMI connector ?
Is TMDS line of HDMI connector terminated by
the TMDS signal of 3.3V and is the signal output?
The pattern and circuit
from the HDMI connector
(JK101/JK111/JK112
/JK113/JK114/JK121/
JK122) to the IC
(IC101/111/121) is
defective.
NO NO
The HDMI input circuitry is defective.
(IC111 or IC121 and surrounding circuitry)
(20) VIDEO CONVERT : Is the picture output when it is set to off?
(After item (23) : To be "VIDEO CONVERT:OFF" setting.)
IC151(ADV8002) and surrounding circuitry
are defective.
YES
NO
YES
YES
YES
YES
Check operation of each device.
(AMP source : BD[i/p:Analog&HDMI,MONITOR OUT:Auto] / Video
input of player : 480P / Connect the TV.)
Check operation of IC111(ADV3002).
(21) Check power supply.
Are 5V or 3.3V supplied to IC111 (each power supply pin)?
Refer to [Detail C] of the substrate for test point.
(22) Check RESET.
Is RESET waveform conrmed in TP[3002_RESET], when power
is turned on?(If the waveform is not the reference waveform,
proceed to NO.)
(24) Check output signal.
Is TMDS waveform conrmed in 25pin/26pin/28pin/29pin/31pin/3
2pin/34pin/35pin.
Is communication waveform of DDC_SCL/DDC_SDA conrmed
in 67pin/68pin? (If the waveform is not the reference waveform,
proceed to NO.)
(23) Check Control signal (I2C).
Is waveform conrmed in TP[HDMI_SCL/HDMI_SDA], when
power is turned on? (If the waveform is not the reference
waveform, proceed to NO.)
The power supply circuitry is defective.
The RESET circuitry (Q1109 and
surrounding circuitry) or IC111 is defective.
The IC111 is defective.
The pattern is defective of the HDMI_SCL/
HDMI_SDA line.
NO
NO
NO
NO

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
