Denon AVR-4311 User Manual

54
ENGLISH
Connect
For speaker impedance and speaker cable connections, see page 5.
2.1-channel connection
FL FR
SW
Bi-Amp connection
You can use the front speakers via the bi-amp connection.
A bi-amp connection is to connect separate amplifiers to the tweeter terminals and woofer terminals of
speakers compatible with the bi-amp function. This prevents the back electromotive force (returned force
without output) of the woofer sent to the tweeter, which affects the sound quality of the tweeter, and you
can enjoy playback with higher-quality sound.
To use the bi-amp connection for the front speakers, select “Amp Assign” and set “Assign Mode” to
“Bi-AMP” using steps 3 and 4 of “Set up “Amp Assign”” (vpage59).
FL FR
SW
wq wq
(R) (L)
z You can also connect the front speakers for bi-amp connection to SURR.BACK/AMP ASSIGN or
F.HEIGHT/AMP ASSIGN speaker terminals using the “Amp Assign” – “Assign Sp.” settings (vpage91).
To perform multichannel playback, connect the center, surround, surround back, and front speakers, and
subwoofer.
NOTE
• Use speakers compatible with bi-amp connections.
• When making bi-amp connections, be sure to remove the short-circuiting plate or wire between the
speaker’s woofer and tweeter terminals.
1.AVR4311E2_ENG_6th_0810.indd 54 2010/08/12 10:11:58

Denon AVR-4311 Specifications

General

Type	AV Receiver
Number of channels	9.2
Output Power per Channel	140 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kohms
Signal-to-Noise Ratio	102 dB
HDMI outputs	2
3D Support	Yes
Network features	AirPlay, DLNA
Audio DAC	24-bit/192kHz
Video Inputs/Outputs	Component
Audio Inputs/Outputs	Analog, Optical, Coaxial
Network Connectivity	Ethernet
Supported Audio Formats	Dolby TrueHD, DTS-HD Master Audio, FLAC, WAV, MP3, WMA, AAC
Dimensions (W x H x D)	434 x 195 x 427 mm
HDMI inputs	7 (1 on front)
