Denon AVR-4802 User Manual

10
1
4
2
3
Connecting the antenna terminals
SPEAKER SYSTEMS
PRE OUT
DVD
YP
B/CB PR/CR
ANTENNA
EXT. IN
FRONT
LOOP ANT.
AM
CENTER
FM COAX. 75Ω
FR FL
SW C
SR SL
SBR SBL
SURROUND
-A
R
R
SURROUND
-B
SIGNAL
GND
PHONO CD
FRONT CENTER SB
SW
SURROUND
DVD
DVD VDP TV
VDP TV
I
R
SB / MULTI
ROOM TO ROOM
POWER
AMP
OUT
OUT IN
R
R
L
R
L
IN
IN
REMOTE CONTROL
DIRECTION OF
BROADCASTING
STATION
AM LOOP ANTENNA
(Supplied)
FM ANTENNA
GROUND
AM OUTDOOR
ANTENNA
FM INDOOR
ANTENNA
(Supplied)
300 Ω/ohms
FEEDER
CABLE
75 Ω/ohms
COAXIAL
CABLE
F-type converter plug (attached)
• When using the FM antenna
attach to this apparatus
AM loop antenna assembly
Connect to the AM
antenna terminals.
Bend in the reverse
direction.
Remove the vinyl tie
and take out the
connection line.
a. With the antenna
on top any stable
surface.
b. With the antenna
attached to a
wall.
Mount
Installation hole
Mount on wall, etc.
Connection of AM antennas
1. Loosen by turning
counterclockwise.
2. Insert the
cord.
3. Tighten by turning
clockwise.
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s
attention to Article 820-40 of the NEC which provides
guidelines for proper grounding and, in particular, specifies
that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as
practical.
Notes:
• Do not connect two FM antennas simultaneously.
• Even if an external AM antenna is used, do not disconnect
the AM loop antenna.
• Make sure AM loop antenna lead terminals do not touch
metal parts of the panel.

Denon AVR-4802 Specifications

General

Impedance	8 ohms
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
THD	0.05%
Signal-to-Noise Ratio	100 dB
Surround Sound	Dolby Digital, DTS, Dolby Pro Logic II
Component Video Inputs	3
Digital Inputs	5 (3 Optical, 2 Coaxial)
Type	AV Receiver
Channels	7.1
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Inputs	5 Digital (3 Optical, 2 Coaxial)
Outputs	composite video, component video, optical digital
Audio D/A Converter	24-bit/192kHz
