Denon AVR-4802 User Manual

54
Tone control setting
• Use the tone control setting to adjust the bass and treble as desired.
1
Display the surround parameter
screen on the monitor.
The screen for the selected
surround mode appears.
“TONE” cannot be selected in
the Direct or Home THX Cinema
mode.
2
Press the CURSOR/PAGE button to
highlight the display, then use the
jog stick to set the parameters.
Select “TONE”.
3
Switch to the Tone Control screen.
4
If you do not want the tone to be adjusted, set “Tone Defeat” to “ON”.
(See page 35.)
B To select Bass or Treble. B To set the level.
5
Enter the setting.
The surround menu screen re-appears.
6
Press the CURSOR/PAGE button so that
the display is no longer highlighted, then
press the “SURR. PARA” button to
complete the setting.
2, 3, 4, 5
1, 6
6
(Remote control unit)
(Remote control unit)
(Remote control unit)
(Remote control unit)
(Remote control unit)
(Remote control unit)
(Remote control unit)
• To operate the tone control from the main unit.
1
The tone switches as follows each time the TONE CONTROL button is pressed.
TONE
CONTROL
2
With the name of the volume to be adjusted selected, turn the SELECT knob to adjust the level.
• To increase the bass or treble:
Turn the control clockwise. (The bass or treble sound can be increased to up to +12 dB in steps of 2 dB.)
• To decrease the bass or treble:
Turn the control clockwise. (The bass or treble sound can be decreased up to –12 dB in steps of 2 dB.)
SELECT
(Main unit)
(Main unit)
1
TREBLE
0
BASS

Denon AVR-4802 Specifications

General

Impedance	8 ohms
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
THD	0.05%
Signal-to-Noise Ratio	100 dB
Surround Sound	Dolby Digital, DTS, Dolby Pro Logic II
Component Video Inputs	3
Digital Inputs	5 (3 Optical, 2 Coaxial)
Type	AV Receiver
Channels	7.1
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Inputs	5 Digital (3 Optical, 2 Coaxial)
Outputs	composite video, component video, optical digital
Audio D/A Converter	24-bit/192kHz
