43
Fader function
• This function makes it possible to lower the volume of the front channels (FL, C and FR) or the rear channels (SL, SR, SBL and SBR) together.
Use it for example to adjust the balance of the sound from the different positions when playing multi-channel music sources.
1
MAIN UNIT:
Press the CH VOL button, and select
“FADER”.
REMOTE CONTROL UNIT:
Select “FADER”.
The channel switches in the order shown below each time
this button is pressed.
2
The fader function does not affect the SW channel.
The channel whose channel level is adjusted lowest can be faded
to –12 dB using the fader function.
If the channel levels are adjusted separately after adjusting the
fader, the fader adjustment values are cleared, so adjust the fader
again.
This is only displayed when setting the fader control.
MAIN UNIT:
Turn the SELECT knob clockwise to
adjust the volume of the surround side
collectively. Turn the CONTROL knob
counterclockwise to adjust the volume
of the front side collectively.
REMOTE CONTROL UNIT:
Press the CURSOR/PAGE button on the
“SURROUND 2/5” page to highlight the
display. The channel (speaker) switches
as shown on the diagram below each
time it is pressed.
REMOTE CONTROL UNIT:
Move jog stick “ENTER” to the top side
to adjust the volume of the surround side
collectively.
Move jog stick “ENTER” to the bottom
side to adjust the volume of the front side
collectively.
