Getting Started Connections Settings Playback Remote ControlMulti-zone Information Troubleshooting SpecificationsSettings
ENGLISH
Setting items Setting contents
Speaker Configuration
(Continued)
Subwoofer : Set the presence of a subwoofer.
Yes : Use a subwoofer.
No : Select when a subwoofer is not connected.
When “Front” is set to “Small”, “Subwoofer” can automatically set
to “Yes”.
•
•
Surround : Set the presence and size of the surround speakers.
Large : Use of a large speaker that can adequately playback low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
None : Select when the surround speakers are not connected.
When “Surround” is set to “Large”, “Surround Back”, “Front Height”
and “Front Wide“ can be set to “Large”.
When “Surround” is set to “None”, “Surround Back”, “Front Height”
and “Front Wide” can automatically set to “None”.
•
•
•
•
•
Surround Back : Set the presence, size and number of surround back
speakers.
Large : Use of a large speaker that can adequately playback low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
None : Select when the surround back speakers are not connected.
2spkrs : Use two surround back speakers.
1spkr : Use only one surround back speaker. When you select this
setting, connect the surround back speaker to the left (L) channel.
When “Configuration” is set to “5.1ch” in the “Amp Assign” settings
or when “SB” is not selected using “Extra Channel”, no settings can be
made for “Surround Back”.
Even when the Surround Back Speaker setting is other than “None”,
sound may not be emitted from the surround back speaker, depending
on the playback source. In this case, “Surround Parameters” – “Surround
Back” setting other than “OFF” (vpage 82).
•
•
•
•
•
•
•
Making Detailed Settings (Manual Setup)
Main remote control unit
operation buttons
:Displaying the menu
Cancel the menu
:Moves the cursor
(Up/Down/Left/Right)
:Confirm the setting :Return to previous menu
Setting items Setting contents
Amp Assign
Change the power
amp assignment to suit
the speaker system
configuration.
Configuration : Select MAIN ZONE channel configuration.
5.1ch / 7.1ch / 9.1ch / 11.1ch•
Extra Channel : Select the channels to be used from among surround
back speakers (SB), front height speakers (FH), front wide speakers (FW).
When setting “Configuration” to “7.1ch”
SB / FH / FW
When setting “Configuration” to “9.1ch”
SB/FH / SB/FW / FH/FW
n
•
n
•
Assign Mode : Select power amp usage method.
NORMAL : This is the usual configuration.
+Z2 : Assign a power amp to ZONE2 audio.
+Z2+Z3 : Assign a power amp to ZONE2 and ZONE3 audio.
ALL Z2 : Assign all power amps to ZONE2 audio.
ALL Z2+Z3 : Assign all power amps to ZONE2 and ZONE3 audio.
FREE : Freely assign power amps to the desired channels.
•
•
•
•
•
•
Front : Select front speaker connection method.
NORMAL : This is the usual configuration.
Bi-WIRING : Bi-wire the front speakers.
Bi-AMP : Bi-amp the front speakers.
2CH BW : Bi-wire another front speaker for 2 channel play mode.
2CH BA : Bi-amp another front speaker for 2 channel play mode.
•
•
•
•
•
Speaker Configuration
Select speaker configuration
and size (bass reproduction
capability).
NOTE
Select “Large” or “Small”
not according to the
physical size of the speaker
but according to the low
frequency reproduction
capabilities based on the
frequency set at “Crossover
Frequency” (vpage 42).
Front : Set the front speaker size.
Large : Use of a large speaker that can adequately playback low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
When “Subwoofer” is set to “No”, “Front” can automatically set to
“Large”.
When “Front” is set to “Small”, “Center”, “Surround“, “Surround
Back”, “Front Height” and “Front Wide“ can not be set to “Large”.
•
•
•
•
Center : Set the presence and size of the center speaker.
Large : Use of a large speaker that can adequately playback low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
None : Select when a center speaker is not connected.
“Large” is not displayed when “Front” is set to “Small”.
•
•
•
To Next Page
