Getting Started Connections Settings Playback Remote ControlMulti-zone Information Troubleshooting SpecificationsSettings
ENGLISH
Setting items Setting contents
Distance
Set distance from listening
position to speakers.
Measure beforehand the
distance from the listening
position to each speaker.
Meters / Feet : Set the unit of distance.
Step : Set the minimum variable width of the distance.
0.1m / 0.01m
1ft / 0.1ft
•
•
Default : Reset all distance settings to factory default.
Yes : Reset to the defaults.
No : Do not reset to the defaults.
When you select “Default” and press ENTER, the “Return all settings
to the default?” prompt is displayed. Select either “Yes” or “No”, and
press ENTER.
•
•
Front L / Front R / Center / Subwoofer / Surround L / Surround R /
Surr. Back L
z
/ Surr. Back R
z
/ Front Height L / Front Height R / Front
Wide L / Front Wide R : Select the speaker.
z: When the “Speaker Configuration” – “Surround Back” setting
(vpage 40) is set to “1spkr”, “Surr. Back” is displayed.
0.00m ~ 18.00m / 0.0ft ~ 60.0ft : Set the distance.
Speakers set to “None” in “Speaker Configuration” (vpage 40) are
not displayed.
The speakers that can be selected differ depending on the “Amp Assign”
(vpage 40) and “Speaker Configuration” (vpage 40) settings.
Default settings :
Front / Center / Subwoofer / Front Height / Front Wide : 3.60 m (12.0 ft)
Surround / Surround Back : 3.00 m (10.0 ft)
Set the difference in the distance between the speakers to less than 6.0
meters (20 feet).
•
•
•
•
•
Channel Level
Set the volume of the test
tone to be the same when it
is output from each speaker.
Test Tone : Output test tone.
Front L / Front Height L / Center / Front Height R / Front R / Front
Wide R / Surround R /Surr. Back R
z
/Surr. Back L
z
/ Surround L /
Front Wide L / Subwoofer : Select the speaker.
z
: When the “Speaker Configuration” – “Surround Back” setting
(vpage 40) is set to “1spkr”, “Surr. Back” is displayed.
–12dB ~ +12dB (0dB) : Adjust the volume.
Speakers set to “None” in the “Speaker Configuration” (vpage 40)
settings are not displayed.
When
o is pressed while the subwoofer volume is set to “–12 dB”, the
“Subwoofer” setting switches to “OFF”.
When a headphones jack is inserted in the PHONES terminal of the AVR-
4810, the “Channel Level” is not displayed.
You can also press
CHANNEL LEVEL to set (vpage 91 “Adjust the
Volume of the Different Speakers“).
•
•
•
•
•
•
Making Detailed Settings (Manual Setup)
Main remote control unit
operation buttons
:Displaying the menu
Cancel the menu
:Moves the cursor
(Up/Down/Left/Right)
:Confirm the setting :Return to previous menu
Setting items Setting contents
Speaker Configuration
(Continued)
Front Height : Set the presence and size of the front height speakers.
Large : Use of a large speaker that can adequately playback low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
None : Select when the front height speakers are not connected.
When “Configuration” is set to “5.1ch” in the “Amp Assign” settings
(vpage 40) or when “FH” is not selected using “Extra Channel”, no
settings can be made for “Front Height”.
•
•
•
Front Wide : Set the presence and size of the front wide speakers.
Large : Use of a large speaker that can adequately playback low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
None : Select when the front wide speakers are not connected.
When “Configuration” is set to “5.1ch” in the “Amp Assign” settings
(vpage 40) or when “FW” is not selected using “Extra Channel”, no
settings can be made for “Front Wide”.
•
•
•
Bass Setting
Settings for subwoofer and
LFE signal range playback.
Subwoofer Mode : Select low range signals to be reproduced by
subwoofer.
LFE : The low range signal of the channel set to “Small” speaker size is
added to the LFE signal output from the subwoofer.
LFE+Main : The low range signal of all channels is added to the LFE
signal output from the subwoofer.
This can be set when “Speaker Configuration” – “Subwoofer” (vpage
40) is set to “Yes”.
Play music or a movie source and select the mode offering the strongest
bass.
Select “LFE+Main” if you want the bass signals to always be produced
from the subwoofer.
•
•
•
•
•
LPF for LFE : Set LFE signal playback range.
80Hz / 90Hz / 100Hz / 110Hz / 120Hz / 150Hz / 200Hz / 250Hz•
See overleaf
To Next Page
