Denon AVR-791 Service Manual

133
Ref. No. Part No. Part Name Remarks Q'ty New
C2 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C3,4 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C5 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C6 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C7 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C8,9 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C10 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C11,12 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C13 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C14 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C15 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C16,17 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C18 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C19 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C22 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C25 nsp C,FILM MI-0.047UF-J/50V D020473167050S
C27 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C30 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C33 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C36 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C39 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C42,45 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C53 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C54 nsp C,FILM 0.1UF-K/250V D02010407H080S
C55 963134010180S C,ELECT 12000UF-M/71V D040123089550S
C57 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C58 963134010180S C,ELECT 12000UF-M/71V D040123089550S
C60 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
C61 nsp C,FILM 0.1UF-K/250V D02010407H080S
C63 nsp C,CERAMIC 1000PF-K/50V D011102777160S
z
C100 963132010140S C,CERAMIC ECQU2A104ML 0.1UF D00810408H000S
C102 963134010200S C,ELECT 100UF-M/400V
D04110108K000S
C103 963132010120S C,CERAMIC DEHR33A102KB2B D00810207Q010S
z
C104,105 963132010160S C,CERAMIC DE1B3KX471KB5B D00847107H010S
C106-108 963134010220S C,ELECT5600UF-M/6.3V D041562081001S
C110 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C111 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C112 963134010190S C,ELECT 10UF-M/50V D041100087050S
C113 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C115 963132010150S C,CERAMIC DE1E3KX222MB5BA01 D00822208H010S
C116 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C117 963132010130S C,CERAMIC DE2F3KH103MB3B AC250V D008103089010S
C118 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
C119 963134010210S C,ELECT 47UF-M/25V D041470084050S
C120-123 nsp C,CERAMIC 0.1UF-K/25V D011104774161S
OTHERS PARTS GROUP
BKT1-3 nsp BRACKET t1.0+Sn plating /PCB MTG 4010214876000S
BKT100 nsp BRACKET 0.8t/SCREW 4010210196100S
BKT101 nsp BRACKET SCREW 4010210196000S
CLAMP3 nsp CLAMP WIRE(SOLDER) 4330000120000S

Denon AVR-791 Specifications

General

Number of Channels	7.1
HDMI Inputs	4
HDMI Outputs	1
Audyssey Technologies	Audyssey MultEQ, Audyssey Dynamic Volume, Audyssey Dynamic EQ
4K Pass-Through	No
Signal-To-Noise Ratio	100 dB
HDMI Switching	Yes
Input Sensitivity	200 mV
THD	0.08%
Surround Sound Effects	Yes
Digital Sound Processor (DSP)	Yes
DSP Preset Qty	7
Tuner Bands	AM/FM
Preset Station Qty	56
Auto Preset Memory	Yes
HDMI Pass-Through	Yes
Frequency Response	10Hz-100kHz
Power Output	90 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Dolby Technologies	Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS Neo:6
Response Bandwidth	10 - 100000 Hz
Input Impedance	47 kΩ
Audio D/A Converter	24-bit / 192kHz
DSP Presets	Rock Arena, Jazz Club, Mono Movie, Matrix, Virtual, Game
Tuning Range	AM: 520 - 1710 kHz, FM: 87.5 - 108 MHz
Connector Type	HDMI
Amplifier Output Details	90W x 7 (8 ohms, 20Hz-20kHz, 0.08% THD)
Video Conversion	Yes (Composite to HDMI)
