Denon AVR-791

PARTS LIST OF EXPLODED VIEW
s
zParts for which "nsp" is indicated on this table cannot be supplied.
z
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
zPart indicated with the mark " ★ " is not illustrated in the exploded view.
zThe parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
1911E3 : U.S.A. & Canada model 1911E2 : Europe model 1911E1C : China model
791E3 : U.S.A. & Canada model 791EA : Australia model
BK : Black model SP : Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
22A nsp PCB FRONT ASSY 1911BKE3 7025HK0922013 1 *
22A nsp PCB FRONT ASSY 791BKEA 7025HK0922023 1 *
22A nsp PCB FRONT ASSY 1911SPE1C 7025HK0922043 1 *
22A nsp PCB FRONT ASSY 1911SPE2 7025HK0922053 1 *
22A nsp PCB FRONT ASSY 1911BKE2 7025HK0922063 1 *
22A nsp PCB FRONT ASSY 791BKE3 7025HK0922073 1 *
11 - PCB FUNCTION
14 - PCB H/P
21 - PCB USB
22 - PCB FRONT
23 - PDB FUNCTION_CNT
26 - PCB GUIDE_L
29 - PCB TOP_GUIDE
31 - PCB GUIDE_R
33 nsp PCB 7CH-AMP ASSY 1911BKE3 7025HK0922010 1 *
33 nsp PCB 7CH-AMP ASSY 791BKEA 7025HK0922020 1 *
33 nsp PCB 7CH-AMP ASSY 1911SPE1C 7025HK0922040 1 *
33 nsp PCB 7CH-AMP ASSY 1911SPE2 7025HK0922050 1 *
33 nsp PCB 7CH-AMP ASSY 1911BKE2 7025HK0922060 1 *
33 nsp PCB 7CH-AMP ASSY 791BKE3 7025HK0922070 1 *
50 nsp PCB AUDIO_VIDEO ASSY 1911BKE3 7025HK0922014 1 *
50 nsp PCB AUDIO_VIDEO ASSY 791BKEA 7025HK0922024 1 *
50 nsp PCB AUDIO_VIDEO ASSY 1911SPE1C 7025HK0922044 1
*
50 nsp PCB AUDIO_VIDEO ASSY 1911SPE2 7025HK0922054 1 *
50 nsp PCB AUDIO_VIDEO ASSY 1911BKE2 7025HK0922064 1 *
50 nsp PCB AUDIO_VIDEO ASSY 791BKE3 7025HK0922074 1 *
53A nsp PCB REG_CNT ASSY 1911BKE3 7025HK0922012 1 *
53A nsp PCB REG_CNT ASSY 791BKEA 7025HK0922022 1 *
53A nsp PCB REG_CNT ASSY 1911BKE1C 7025HK0922042 1 *
53A nsp PCB REG_CNT ASSY 1911BKE2 7025HK0922052 1 *
53A nsp PCB REG_CNT ASSY 1911BKE2 7025HK0922062 1 *
53A nsp PCB REG_CNT ASSY 791BKE3 7025HK0922072 1 *
51 - PCB SIDE_CNT
52 - PCB REG
53 - PCB REG_CNT
57 - PCB FRONT_CNT
54A nsp PCB SPK ASSY 1911BKE3 7025HK0922011 1 *
54A nsp PCB SPK ASSY 791BKEA 7025HK0922021 1 *
54A nsp PCB SPK ASSY 1911SPE1C 7025HK0922041 1 *
54A nsp PCB SPK ASSY 1911SPE2 7025HK0922051 1 *
54A nsp PCB SPK ASSY 1911BKE2 7025HK0922061 1 *
Ref. No. Part No. Part Name Remarks Q'ty New
54A nsp PCB SPK ASSY 791BKE3 7025HK0922071 1 *
54 - PCB SPK
55 - PCB SMPS
56 8U6331005700S PCB HDMI ASSY 1911BKE3 7025HK0922016 1 *
56 8U6331005800S PCB HDMI ASSY 791BKE3 7025HK0922076 1 *
56 nsp PCB HDMI ASSY 791BKEA 7025HK0922026 1 *
56 nsp PCB HDMI ASSY 1911SPE1C 7025HK0922046 1 *
56 nsp PCB HDMI ASSY 1911SPE2 7025HK0922056 1 *
56 nsp PCB HDMI ASSY 1911BKE2 7025HK0922066 1 *
1 963416010070D WINDOW DISPLAY 1911BKE3,791BKE3 5077212762060S 1 *
1 963416011350D WINDOW DISPLAY
1911SPE2,1911BKE2,1911SPE1C,
791BKEA
5077212762080S 1 *
2 963412000570D KNOB FUNCTION(KD) BK 5080211761000SZ 1
2 412510003031D KNOB FUNCTION SP 5087211901000S 1
3 00D9630362109 BADGE DENON BK 5630210028300S 1
3 00D9630362202 BADGE DENON SP 5630210028400S 1
4 963402009830D PANEL FRONT 1911BKE3 3067214911300S 1 *
4 963402009860D PANEL FRONT 1911BKE2 3067214911400S 1 *
4 963402009870D PANEL FRONT 1911SPE2 3067214911500S 1 *
4 963402009880D PANEL FRONT 1911SPE1C 3067214911510S 1 *
4 963402009840D PANEL FRONT
791BKE3 3067214921210S 1 *
4 963402009850D PANEL FRONT 791BKEA 3067214921310S 1 *
5 00D9630137807 LENS STANDBY 3710210503000S 1
6 nsp CUSHION SIDE 4050213095000S 2 *
7 963411002820S BUTTON-ASSY STANDBY(KD) BK 5098212361000SZ 1
7 00D9630221904 BUTTON-ASSY STANDBY SP 5097212368030SZ 1
8 00D9630362305 BUTTON 2KEY 1911BKE3,1911BKE2 5097213351000S 1
8 00D9630362501 BUTTON 2KEY 1911SPE2,1911SPE1C 5097213351110S 1
8 963411001390D BUTTON 2KEY 791BKE3,791BKEA 5097213591000S 1
12 963419010060D COVER RCA BK 4317215141000S 1 *
12 963419011380D COVER RCA SP 4317215141100S 1 *
15 963412000560D KNOB VOLUME(KD) BK 5080211751000SZ 1
15 412510002038D KNOB VOLUME SP 5087211891000S 1
16 963411003370D BUTTON 1KEY 1911BKE3,1911BKE2 5097213791000S 1
16 963412003670D BUTTON 1KEY 1911SPE2,1911SPE1C 5097213791100S 1
16-1 963411003770D BUTTON 1KEY 791BKE3,791BKEA 5097213801000S 1
17 963411003380D BUTTON CURSOR 5KEY BK 5097213811000S 1
17 963411003680D BUTTON CURSOR 5KEY SP 5097213811100S 1
18 00D9630364700 BUTTON 3KEY 1911BKE3,1911BKE2 5097213331000S 1
18 00D9630364906 BUTTON 3KEY 1911SPE2,1911SPE1C 5097213331110S 1
18-1 963411001410D BUTTON 3KEY B BK 5097213611000S 1
18-1 963411011340D BUTTON 3KEY B SP 5097213611100S 1 *
18-2
963411001400D BUTTON 3KEY A 791BKE3,791BKEA 5097213601000S 1
94
NOTE :
Please change the destination-resistors when changing 791BKE3 (8U6331005800S)
to other destination.
Please refer to destination-resistors 88,89 page.
(SCHEMATIC DIAGRAMS : 20/23, 21/23)
R2906(20/23) R3122(21/23) R3119(21/23)
791BKE3 OPEN 18K 3.3K
791BKEA OPEN 3.3K 18K
1911BKE2 33 10K OPEN
1911SPE1C OPEN 10K 10K
