Denon AVR-791 Service Manual

EXPLODED VIEW
s
C X1
A X23
I
P
P
4
3
2
1
11
23
5
7
18
20
12
21
14
8
T X6
15
AVR1911 ALL
AVR791
17
16
19
19
18 -1
22
61
I
76
G X3
G X3
D X3
P
P
4
3
2
1
15
18 -2
5
7
12
8
T X6
E X21
28
T X5
32 X5
26
T
46
42
41 X4
40 X4
70
73
72
T x4
H x4
T x3
T
D
18 -1
44
T x2
17
16 -1
T X5
33
50
56
52
53
54
55
29
Q X5
(HDMI)
T
14
57
51
91
19
19
20
43 x3
27
31
45
T
T
82
82
T
T
F
F
T
F
T
59
T
60
T
T
6
6
PCB
GUIDE CABLE
BACK
C X1
A X23
11
23
21
22
61
z
z
83
77 X6
78
AVR1911 BKE2/SPE2
AVR791 BKEA
G X2
Parts marked with this symbol have critical
characteristics.
Use ONLY replacement parts recommended by
the manufacturer.
WARNING:
印の部分は安全を維持するために重要
な部品です。従って交換時は必ず指定の
部品を使用してください。
93

Denon AVR-791 Specifications

General

Number of Channels	7.1
HDMI Inputs	4
HDMI Outputs	1
Audyssey Technologies	Audyssey MultEQ, Audyssey Dynamic Volume, Audyssey Dynamic EQ
4K Pass-Through	No
Signal-To-Noise Ratio	100 dB
HDMI Switching	Yes
Input Sensitivity	200 mV
THD	0.08%
Surround Sound Effects	Yes
Digital Sound Processor (DSP)	Yes
DSP Preset Qty	7
Tuner Bands	AM/FM
Preset Station Qty	56
Auto Preset Memory	Yes
HDMI Pass-Through	Yes
Frequency Response	10Hz-100kHz
Power Output	90 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Dolby Technologies	Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS Neo:6
Response Bandwidth	10 - 100000 Hz
Input Impedance	47 kΩ
Audio D/A Converter	24-bit / 192kHz
DSP Presets	Rock Arena, Jazz Club, Mono Movie, Matrix, Virtual, Game
Tuning Range	AM: 520 - 1710 kHz, FM: 87.5 - 108 MHz
Connector Type	HDMI
Amplifier Output Details	90W x 7 (8 ohms, 20Hz-20kHz, 0.08% THD)
Video Conversion	Yes (Composite to HDMI)
