Denon AVR-791 Service Manual

136
Ref. No. Part No. Part Name Remarks Q'ty New
C137 00D9630234205 C,ELECT 10UF-M/50V 1911E2,1911E1C,791E3,791EA D040100087070S
C139,140 963134011280S C,ELECT 470UF-M/25V 1911E2,1911E1C,791EA D040471084060S
C142-144 nsp C,FILM 0.1UF-J/50V D020104167050S
C146-148 nsp C,FILM 0.1UF-J/50V D020104167050S
OTHERS PARTS GROUP
BKT101 nsp BRACKET 0.8t/SCREW 4010210196100S
CLAMP101 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN10 nsp CN,WAFER 11P L109012521110S *
CN11 nsp CN,WAFER 25P L109012522510S *
CN13 nsp CN,WIRE 2MM 120MM/13P L002121130010S *
CN15 nsp CN,WIRE 2MM 120MM/4P L002121040110S *
CN100 nsp CN,WAFER 13P L109012521310S *
CN101 nsp CN,WAFER11P L109012521110S *
CN102 nsp CN,WAFER 17P L109012521710S *
CN103 nsp CN,WAFER 19P L109012521910S *
CN104 nsp CN,WAFER 27P L109012522710S *
CN105 nsp CN,WAFER 17P L109012521710S *
CP3 nsp CN,WAFER 11P L109012511110S *
CP4 nsp CN,WAFER 25P L109012512510S *
CP13A nsp CN.WAFER 13P L101200101320S
CP14 nsp CN.WAFER 4P L101200100420S
CP100 nsp CN,WAFER 13P L109012511310S *
CP101 nsp CN,WAFER 11P L109012511110S *
CP102 nsp CN.WAFER 4P L102526700400S
CP104 nsp CN.WAFER 3P L102526700300S
CP105 nsp CN,WAFER 19P L109012511910S *
CP106 nsp CN,WAFER 17P L109012511710S *
CP108 nsp CN,WAFER 19P L109012511910S *
CP109 nsp CN,WAFER17P L109012511710S *
CP110 nsp CN.WAFER33P L109012513310S *
CP801 nsp CN.FPC 1.25-2-13P 1911E3 L131125021310S
z
F104 963652010500S FUSE T1.6A/250V 1911E2,1911E1C,791EA N751501601160S *
z
F105-108 963652010500S FUSE T1.6A/250V N751501601160S *
F104A, F104B nsp HOLDER,FUSE CLIP 1911E2,1911E1C,791EA G645000050010S
F105A-108A nsp HOLDER,FUSE CLIP G645000050010S
F105B-108B nsp HOLDER,FUSE CLIP G645000050010S
nsp BRACKET SCREW 4010210196000S

Denon AVR-791 Specifications

General

Number of Channels	7.1
HDMI Inputs	4
HDMI Outputs	1
Audyssey Technologies	Audyssey MultEQ, Audyssey Dynamic Volume, Audyssey Dynamic EQ
4K Pass-Through	No
Signal-To-Noise Ratio	100 dB
HDMI Switching	Yes
Input Sensitivity	200 mV
THD	0.08%
Surround Sound Effects	Yes
Digital Sound Processor (DSP)	Yes
DSP Preset Qty	7
Tuner Bands	AM/FM
Preset Station Qty	56
Auto Preset Memory	Yes
HDMI Pass-Through	Yes
Frequency Response	10Hz-100kHz
Power Output	90 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Dolby Technologies	Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS Neo:6
Response Bandwidth	10 - 100000 Hz
Input Impedance	47 kΩ
Audio D/A Converter	24-bit / 192kHz
DSP Presets	Rock Arena, Jazz Club, Mono Movie, Matrix, Virtual, Game
Tuning Range	AM: 520 - 1710 kHz, FM: 87.5 - 108 MHz
Connector Type	HDMI
Amplifier Output Details	90W x 7 (8 ohms, 20Hz-20kHz, 0.08% THD)
Video Conversion	Yes (Composite to HDMI)
