Denon AVR-791 Service Manual

139
Ref. No. Part No. Part Name Remarks Q'ty New
CN102 nsp CN,WIRE 2MM 450MM/5P L002451050120S *
CP100 nsp CN.WAFER 5P L101200100510S
CP100_1 nsp 5268-07A 7P ANGLE L102526800700S
CP102 nsp CN.WAFER 2.0MM 8P L101100030810S
CP103,104 nsp CN.WAFER 8P L101100040810S
CP105 nsp CN.WAFER 2.0MM 8P L101100030810S
G101 nsp RING,TER WIRE 100MM/1P 8410101010240S
JACK100 00D9630367802 JACK,D3.5 EARPHONE G401PJ354H40YS
JACK101 963649010300S CN,PLUG DIP4P BK USBAS-00401B014-G G480040101410S *
JACK102 00D9630146403 TER,RCA 3PIN G606308HG110YS
JK100 00D9630294708 JACK,D6.5 PHONE G402PJ612AG0YS
L100 nsp COIL INDUCTOR 100UH D330101001020S
RMC100 963262010290S MODULE,REMOCON R34FS9A E940349003810S
SW100-123 00D9630095305 SW,TACT SKHV10910D01 G180040500010S
VEC100,101 00D9630387408 SW,ENCODER EC16B24SO G121162400070S
U1 nsp CN.FPC 1.0MM 1.0-11S-40PW 40P L130100114050S *
U100 963172010470S DISPLAY,FLT 18-ST-13GINK K530180130010S
JP209-213 nsp R,CHIP 0-J,1/8W C200000061300S
nsp HOLDER FLT 4320200026000S

Denon AVR-791 Specifications

General

Number of Channels	7.1
HDMI Inputs	4
HDMI Outputs	1
Audyssey Technologies	Audyssey MultEQ, Audyssey Dynamic Volume, Audyssey Dynamic EQ
4K Pass-Through	No
Signal-To-Noise Ratio	100 dB
HDMI Switching	Yes
Input Sensitivity	200 mV
THD	0.08%
Surround Sound Effects	Yes
Digital Sound Processor (DSP)	Yes
DSP Preset Qty	7
Tuner Bands	AM/FM
Preset Station Qty	56
Auto Preset Memory	Yes
HDMI Pass-Through	Yes
Frequency Response	10Hz-100kHz
Power Output	90 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Dolby Technologies	Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS Neo:6
Response Bandwidth	10 - 100000 Hz
Input Impedance	47 kΩ
Audio D/A Converter	24-bit / 192kHz
DSP Presets	Rock Arena, Jazz Club, Mono Movie, Matrix, Virtual, Game
Tuning Range	AM: 520 - 1710 kHz, FM: 87.5 - 108 MHz
Connector Type	HDMI
Amplifier Output Details	90W x 7 (8 ohms, 20Hz-20kHz, 0.08% THD)
Video Conversion	Yes (Composite to HDMI)
