Denon AVR-791 Service Manual

141
Ref. No. Part No. Part Name Remarks Q'ty New
C837 nsp C,CERAMIC 330PF-J/50V D010331167160S
C838,839 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C840 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C842 nsp C,CERAMIC 330PF-J/50V D010331167160S
C844 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C845 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C846 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C847 nsp C,CERAMIC 330PF-J/50V D010331167160S
C852,853 00D9630224503 C,ELECT 22UF-M/50V 1911E3 D040220087060S
C854 nsp C,CERAMIC 330PF-J/50V D010331167160S
C855 nsp C,CERAMIC 330PF-J/50V 1911E3 D010331167160S
C856 nsp C,CERAMIC 330PF-J/50V D010331167160S
C857 nsp C,CERAMIC 330PF-J/50V 1911E3 D010331167160S
C858 00D9609010023 C,ELECT 0.47UF-M/50V 1911E3 D040R47087050S
C859,860 00D9630224503 C,ELECT 22UF-M/50V 1911E3 D040220087060S
C862-864 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C867 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C868,869 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C870 nsp C,CERAMIC 100PF-J/50V D010101167160S
C871 00D9609010023 C,ELECT 0.47UF-M/50V D040R47087050S
C872 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C875 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C876-880 nsp C,CERAMIC 100PF-J/50V 791E3 D010101167160S
C881 nsp C,CERAMIC 0.1UF-K/50V 791E3 D011104577160S
C882 nsp C,CERAMIC 100PF-J/50V 1911E2, 1911E1C,791EA D010101167160S
C883 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C884 nsp C,CERAMIC 100PF-J/50V 1911E2, 1911E1C,791EA D010101167160S
C885 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C886 nsp C,CERAMIC 100PF-J/50V 1911E2, 1911E1C,791EA D010101167160S
C887 nsp
C,CERAMIC 33PF-J/50V 1911E2, 1911E1C,791EA D010330167160S
C888-889 nsp C,CERAMIC 100PF-J/50V 1911E2, 1911E1C,791EA D010101167160S
C903,904 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C905,906 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C907 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C909 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C910 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C911 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C912 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C913 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C914,915 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C916,917 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C918 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C919 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C920 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C921 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C922 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C923 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C924 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C925 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C926 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C927 nsp C,CERAMIC HIK X7R1200PF-K/50V D011122777160S
C928 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C929 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C930 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C931,932 nsp C,CERAMIC 0.01UF-K/50V D010103777160S

Denon AVR-791 Specifications

General

Number of Channels	7.1
HDMI Inputs	4
HDMI Outputs	1
Audyssey Technologies	Audyssey MultEQ, Audyssey Dynamic Volume, Audyssey Dynamic EQ
4K Pass-Through	No
Signal-To-Noise Ratio	100 dB
HDMI Switching	Yes
Input Sensitivity	200 mV
THD	0.08%
Surround Sound Effects	Yes
Digital Sound Processor (DSP)	Yes
DSP Preset Qty	7
Tuner Bands	AM/FM
Preset Station Qty	56
Auto Preset Memory	Yes
HDMI Pass-Through	Yes
Frequency Response	10Hz-100kHz
Power Output	90 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Dolby Technologies	Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS Neo:6
Response Bandwidth	10 - 100000 Hz
Input Impedance	47 kΩ
Audio D/A Converter	24-bit / 192kHz
DSP Presets	Rock Arena, Jazz Club, Mono Movie, Matrix, Virtual, Game
Tuning Range	AM: 520 - 1710 kHz, FM: 87.5 - 108 MHz
Connector Type	HDMI
Amplifier Output Details	90W x 7 (8 ohms, 20Hz-20kHz, 0.08% THD)
Video Conversion	Yes (Composite to HDMI)
