Denon AVR-791 Service Manual

148
Ref. No. Part No. Part Name Remarks Q'ty New
C2728 nsp C,CERAMIC 0.1UF-K/16V D011102177101S
C2729,2730 nsp C,CERAMIC 470PF-K/50V D011471177101S
C2901-2903 nsp C,CERAMIC 0.1UF-K/16V D011102177101S
C2906-2908 nsp C,CERAMIC 0.1UF-K/16V D011102177101S
C2909 nsp C,CERAMIC 0.01UF-K/25V D011103774102S
C2910 nsp C,CERAMIC 0.1UF-K/16V D011102177101S
C2911-2914 nsp C,CERAMIC 0.01UF-K/25V D011103774102S
C3101 nsp C,CERAMIC 0.1UF-K/16V D011102177101S
C3102 nsp C,CERAMIC 1000PF-K/50V 1911E3 D011102177101S
C3103 nsp C,CERAMIC 0.1UF-K/16V 1911E3 D011104177101S
C3104 nsp C,CERAMIC 1000PF-K/50V 1911E3 D011102177101S
C3111-3113 nsp C,CERAMIC 0.1UF-K/16V D011102177101S
C3114 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C3120 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C3121 nsp C,CERAMIC 0.1UF-K/16V D011102177101S
C3122,3123 nsp C,CERAMIC 10PF-D/50V D011100117101S
C3124-3128 nsp C,CERAMIC 0.1UF-K/16V D011102177101S
C3301-3302 nsp C,CERAMIC 0.1UF-K/16V D011102177101S
C3303,3304 nsp C,CERAMIC T.C COG10PF-D/50V D010100117160S
C3305-3306 nsp C,CERAMIC 0.1UF-K/16V D011102177101S
C3307 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C3315 nsp C,CERAMIC 0.1UF-K/16V D011102177101S
C3316 nsp C,CERAMIC 220PF-K/50V D011221177101S
C3317 nsp C,CERAMIC 0.1UF-K/16V D011102177101S
C9151-9155 nsp C,CERAMIC 1000PF-K/50V D011102177101S
OTHERS PARTS GROUP
L1001 nsp COIL,BEAD CBW160808U121T D340160811210S
L1301-1303 nsp COIL,BEAD CBW160808U121T D340160811210S
L1501-1503 nsp COIL,CHIP FLC32C220K D307322205520S
L2301-2303 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L2501-2506 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L2513-2515 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L2516 nsp COIL,BEAD CBW160808U121T D340160811210S
L2767,2768 nsp R,THICK 0-J,1/16W C20000006M160S
X1001,1002 141810044504S CRYSTAL CHIP FCX-04(28.63636MHz) E80528R636380S *
X1301 141810045507S CRYSTAL CHIP FCX-04(27MHz) E80527R000080S *
X1701 141810046500S CRYSTAL CHIP FCX-04(24.576MHz) E80524R576080S *
X1902 141810047503S CRYSTAL CHIP FCX-04(20.815MHz) E80520R815080S *
X2302 963141010270S CRYSTAL CHIP FCX-04C(12MHz) E80512R000080S *
X3102 141810048506S CRYSTAL CHIP FCX-04(16MHz) E80516R000080S *
X3302 141810048506S CRYSTAL CHIP FCX-04(16MHz) E80516R000080S *
Z1 nsp CLAMP STYLE PIN 1P 4330210162000S
K1001-1004 nsp CN.WAFER 19P L109100190450S *
K1501 nsp CN.WAFER 19P L109100190450S *
K1702 00D9630237503 MODULE JSR1165-C E100116500040S
K1706 963643003580S TER,RCA 1PIN G600107C0020YS
K3101 00D9630294601 JACK,D3.5 EARPHONE G40100350000YS
K3102,3103 00D9630244703 JACK,D3.5 EARPHONE 1911E3 G40130802000YS

Denon AVR-791 Specifications

General

Number of Channels	7.1
HDMI Inputs	4
HDMI Outputs	1
Audyssey Technologies	Audyssey MultEQ, Audyssey Dynamic Volume, Audyssey Dynamic EQ
4K Pass-Through	No
Signal-To-Noise Ratio	100 dB
HDMI Switching	Yes
Input Sensitivity	200 mV
THD	0.08%
Surround Sound Effects	Yes
Digital Sound Processor (DSP)	Yes
DSP Preset Qty	7
Tuner Bands	AM/FM
Preset Station Qty	56
Auto Preset Memory	Yes
HDMI Pass-Through	Yes
Frequency Response	10Hz-100kHz
Power Output	90 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Dolby Technologies	Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS Neo:6
Response Bandwidth	10 - 100000 Hz
Input Impedance	47 kΩ
Audio D/A Converter	24-bit / 192kHz
DSP Presets	Rock Arena, Jazz Club, Mono Movie, Matrix, Virtual, Game
Tuning Range	AM: 520 - 1710 kHz, FM: 87.5 - 108 MHz
Connector Type	HDMI
Amplifier Output Details	90W x 7 (8 ohms, 20Hz-20kHz, 0.08% THD)
Video Conversion	Yes (Composite to HDMI)
