Denon AVR-791 Service Manual

30
4
ENGLISH
Surround
Surround mode NOTE
Input signal types and formats
ANALOG
PCM DTS-HD DTS DOLBY DOLBY DIGITAL
LINEAR PCM
(multi ch)
LINEAR PCM
(2ch)
DTS-HD
Master
Audio
DTS-HD
High
Resolution
Audio
DTS
EXPRESS
DTS ES
DSCRT
(With Flag)
DTS ES
MTRX
(With Flag)
DTS
(5.1ch)
DTS 96/24
DOLBY
TrueHD
DOLBY
DIGITAL Plus
DOLBY
DIGITAL EX
(With Flag)
DOLBY
DIGITAL EX
(With no
Flag)
DOLBY
DIGITAL
(5.1/5/4ch)
DOLBY
DIGITAL
(4/3ch)
DOLBY
DIGITAL
(2ch)
MULTI CH IN
MULTI CH IN
F
MULTI CH IN + PLgx CINEMA z2z3 S MULTI CH IN + PLgx MUSIC z1z3 S MULTI CH IN + PLgz z4 S MULTI CH IN + Dolby EX
z1z3 S
MULTI CH IN 7.1
z3 F D (7.1)
DIRECT
DIRECT
S S S S S S S S S S S S S S S S S
PURE DIRECT
PURE DIRECT
S S S S S S S S S S S S S S S S S
DSP SIMULATION
MULTI CH STEREO
S S S S S S S S S S S S
ROCK ARENA
S S S S S S S S S S S S
JAZZ CLUB
S S S S S S S S S S S S
MONO MOVIE
S S S S S S S S S S S S
VIDEO GAME
S S S S S S S S S S S S
MATRIX
S S S S S S S S S S S S
VIRTUAL
S S S S S S S S S S S S
STEREO
STEREO
F S F S S S S S S S S S S S S S S
z1 If “Speaker Config.“ – “S.Back“ is set to “None”, this surround mode cannot be selected. z2 If “Speaker Config.“ – “S.Back“ is set to “1sp” or “None”, this surround mode cannot be selected. z3 This surround mode can be selected when “Amp Assign” is set to “Normal”. z4 If “Speaker Config.“ – “Front Height“ is set to “None”, this surround mode cannot be selected.

Denon AVR-791 Specifications

General

Number of Channels	7.1
HDMI Inputs	4
HDMI Outputs	1
Audyssey Technologies	Audyssey MultEQ, Audyssey Dynamic Volume, Audyssey Dynamic EQ
4K Pass-Through	No
Signal-To-Noise Ratio	100 dB
HDMI Switching	Yes
Input Sensitivity	200 mV
THD	0.08%
Surround Sound Effects	Yes
Digital Sound Processor (DSP)	Yes
DSP Preset Qty	7
Tuner Bands	AM/FM
Preset Station Qty	56
Auto Preset Memory	Yes
HDMI Pass-Through	Yes
Frequency Response	10Hz-100kHz
Power Output	90 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Dolby Technologies	Dolby Digital Plus, Dolby TrueHD
DTS Technologies	DTS, DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS Neo:6
Response Bandwidth	10 - 100000 Hz
Input Impedance	47 kΩ
Audio D/A Converter	24-bit / 192kHz
DSP Presets	Rock Arena, Jazz Club, Mono Movie, Matrix, Virtual, Game
Tuning Range	AM: 520 - 1710 kHz, FM: 87.5 - 108 MHz
Connector Type	HDMI
Amplifier Output Details	90W x 7 (8 ohms, 20Hz-20kHz, 0.08% THD)
Video Conversion	Yes (Composite to HDMI)
