97
Examples of menu screen displays
Typical examples are described below.
GExample 1H
Menu selection screen (Top menu)
Audio
Dialog Level
Subwoofer Level
Surround Parameter
Tone
Restorer
Audio Delay
Volume
Audyssey
Graphic EQ
Adjusts the center channel volume, making movie
dialogue easier to hear
q Currently selected setup item
w List of GUI menu setup items
Use ui to select “Audio”
and then press p.
(Or press ENTER.)
r
e
Setup Menu
Audio
Video
Inputs
Speakers
Network
General
Setup Assistant
q
w
e Selected setup item
r Guide text for the currently selected setup item
GExample 2H
Audyssey
®
Setup screen (with illustration)
Audyssey Setup
Channel Select
Amp Assign
Check Results
Restore...
Start
Your AV receiver can automatically measure the acoustics of
your room then optimize your speakers using the included
microphone.
Set the following items
if necessary.
y
i
u
t Currently selected setup icon
y Operation guidance text
u Illustration
i Selected setup item
t
NOTE
When the menu is operated on a computer’s resolution (e.g. VGA)
or during playback of certain 3D video content, the playback image
switches to the menu screen image.
Basic instructions
Advanced instructions
Information
Advanced instructions
DVD

Denon AVR-E400 Specifications

General

HDMI Inputs	6
HDMI Outputs	1
3D Pass-through	Yes
4K Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Audyssey MultEQ	Yes
Network Connectivity	Yes
AirPlay	Yes
DLNA	Yes
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Signal-To-Noise Ratio	100 dB
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Tuner Presets	56
Tuner Bands	AM/FM
Frequency Response	10 Hz - 100 kHz
Video Upscaling	Yes
Bluetooth	No
Wi-Fi	No
Surround Sound Effects	DTS Neo:6
Audio D/A Converter	192kHz/24-bit
Inputs	HDMI, Digital Optical, Digital Coaxial, Analog
Outputs	HDMI, Headphones
