Speaker connection
Connecting 7.1-channel speakers using surround back speakers
The illustration on the right shows a connection example for performing 7.1-channel playback using the
surround back speakers.
To perform 7.1-channel playback using the surround back speakers, set “Assign Mode” to “Surround
Back” in steps 3 to 5 for “Set up “Amp Assign”” (vpage86).
NOTE
•For speaker cable connections, see page79.
•For speaker impedance, see page79.
FL FR
C
SL
SR
SW
SBL SBR
