DISASSEMBLY
• Remove each part in the order of the arrows below.
• Reassemble removed parts in the reverse order.
• Read
"Precautions During Work"
before reassembling removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing the
work. Failure to shape the wires correctly may cause problems such as noise.
FRONT PANEL ASSY
See "
DISASSEMBLY
"
1. FRONT PANEL ASSY
and "
EXPLODED VIEW
"
FRONT PCB
(Ref. No. of EXPLODED VIEW : P1)
ENCODER&POWER PCB
(Ref. No. of EXPLODED VIEW : P2)
PHONE PCB
(Ref. No. of EXPLODED VIEW : P3)
iPODUSB_MIC PCB
(Ref. No. of EXPLODED VIEW : P4)
HDMI_FFC_CABLE PCB
(Ref. No. of EXPLODED VIEW : P5)
FRONT_HDMI PCB
(Ref. No. of EXPLODED VIEW : P6)
BLUETOOTH PCB
(Ref. No. of EXPLODED VIEW : P7)
TOP COVER
REGULATOR PCB
See "
DISASSEMBLY
"
5. REGULATOR PCB
and "
EXPLODED VIEW
"
REGULATOR PCB
(Ref. No. of EXPLODED VIEW : P15)
TRANS POWER
See "
DISASSEMBLY
"
5. TRANS POWER
and "
EXPLODED VIEW
"
TRANS POWER
(Ref. No. of EXPLODED VIEW : P21)
RADIATOR ASSY
See "
DISASSEMBLY
"
3. RADIATOR ASSY
and "
EXPLODED VIEW
"
MAIN PCB
(Ref. No. of EXPLODED VIEW : P8)
HDMI CABLE GUIDE PCB
(Ref. No. of EXPLODED VIEW : P9)
FRONT CABLE GUIDE PCB
(Ref. No. of EXPLODED VIEW : P10)
BT WIRE GUIDE PCB
(Ref. No. of EXPLODED VIEW : P11)
BAIS TR PCB
(Ref. No. of EXPLODED VIEW : P12)
TEMP_DETECT PCB
(Ref. No. of EXPLODED VIEW : P13)
DIFF-AMP PCB
(Ref. No. of EXPLODED VIEW : P16)
PHONE WIRE GUIDE PCB
(Ref. No. of EXPLODED VIEW : P22)
DIGITAL PCB ASSY
See "
DISASSEMBLY
"
2. DIGITAL PCB ASSY
and "
EXPLODED VIEW
"
DIGITAL PCB
(Ref. No. of EXPLODED VIEW : P17)
ADAPTER PCB
(Ref. No. of EXPLODED VIEW : P18)
CX870 MODULE
(Ref. No. of EXPLODED VIEW : P19)
TUNER PCB
(Ref. No. of EXPLODED VIEW : P20)
SMPS PCB
See "
DISASSEMBLY
"
4. SMPS PCB
and "
EXPLODED VIEW
"
SMPS PCB
(Ref. No. of EXPLODED VIEW : P14)
12
