Denon AVR-S700W Service Manual

1.4. Error display
See the table below for descriptions of displayed errors and countermeasures for these.
Display order is
q
,
w
,
e
,
r
.
Condition States Display TROUBLE SHOOTING
q
Firm Check
NG
The model name, brand name and
region information written in the rmware
are compared to the region settings in
the PCB.This error is displayed if the
information does not match.
"▲" or "▼" is displayed as the rst
character if the rmware is not correct (see
right section of table).
F I R M E R R O R
–
M a i n : * * * * * * * *
–
D S P : * * . * *
–
A u d i o P L D : * * . * *
–
G U I : * * * * * * * *
• Check the resistor for
setting region(R7581 /
R7582, DIGITAL PCB).
• Write the rmware for
the correct region.
w
DIR NG
This error is displayed if there is no
response from the DIR.
D I R E R R O R 0 1
• Check the DIR (IC772,
DIGITAL PCB) and
surrounding circuits.
e
DSP NG
The DSP FLAG0 port does not enter "
Hi
"
status even after executing a DSP reset
during a DSP code boot.
D S P E R R O R 0 1
• Check the DSP (IC781,
DIGITAL PCB) and
surrounding circuits.
The DSP FLAG0 port does not enter "
Hi
"
status before issuing a DSP command.
D S P E R R O R 0 2
ACK="
Hi
" does not occur during DSP data
reading, even when WRITE="
Lo
".
D S P E R R O R 0 3
ACK="
Lo
" does not occur during DSP
data reading, even when REQ="
Lo
".
D S P E R R O R 0 4
ACK="
Hi
" does not occur during DSP data
writing, even when WRITE="
Hi
".
D S P E R R O R 0 5
ACK="
Lo
" does not occur during DSP
data writing, even when REQ="
Lo
".
D S P E R R O R 0 6
r
EEPROM NG
An error occurred in a checksum of the
EEPROM(*** is a block address number).
E 2 P R O M E R R * * *
20

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
