Denon AVR-S700W Service Manual

1.5. Version Display in the Setup Menu
Follow the steps below to display the rmware information.
(1) Press the "
SETUP
" button on the remote control.
(2) Select "
General - Information - Firmware
".
The version information is displayed as a 12-digit number as shown in the screenshot below.
This 12-digit number comprises part of the version number of each device and module.
These version numbers correspond to the 12-digit number as shown below.
b
The rmware version numbers and this 12-digit version information are written in the Service Information.
General/Firmware
Version
XXXX - XXXX - XXXX
GUI Image
Mainμcom 0 0 2 3 0 0 1 6
Info display
5 2 0 0 - 3 2 6 1 - 6 0 8 5
DSP 8 6 0 2
A.PLD 2 7 0 5
GUI 6 7 1 1 0 0 0 6
DM860 FBL 1 3 1 0 2 8
DM860 SBL B 2 0 1 2 0 9 2 1 0 5 4 6
DM860 IMG I 2 0 1 2 1 0 2 2 0 9 5 8
The 1st digit from the right for DSP
The 1st digit from the right for A.PLD
The 1st digit from the right for IMG
The 2nd digit from the right for IMG
The 1st digit from the right for GUI
The 2nd digit from the right for GUI
The 6th digit from the right for Main μcom
The 5th digit from the right for Main μcom
The 2nd digit from the right for Main μcom
The 1st digit from the right for Main μcom
21

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
