Denon AVR-S700W Service Manual

BLOCK DIAGRAM
AVR-S700W/X1100W GND DIAGRAM
FRONT B'D
H/P GND
H/P B'D
AC CORD
REGULATOR B'D
SR GND SL GND C GND FR GND FL GND
SPEAKER OUT
MAIN B'D
SW GND
ZONE2 GND
PRE OUT
C GND
SR GND
FR GND
SL GND FL GND
PRE FL GND PRE SL GND
PRE C GND
PRE SR GND PRE FR GND
NJU72340AFH3
MASTER
VOLUME
+12V +5V
DGND(HDMI)
AGND(MIC)
DGND(HDMI)
DGND
H/P GND
D GND
A GND / PRE RETURN GND
A GND
S1
FUNCTION KEY
TUNER
ANALOG
INPUT
SMPS B'D
DIGITAL B'D
OPTICAL
COAXIAL
DSP
DIR/ADC
VIDEO
INPUT/OUT
CPU
HDMI
IN/OUT
TUNER
S1
BRIDGE B'D
VKK GND
VKK GND
H/P GND
+B
-B
V GND
S2
USB B'D
DGND
MIC B'D
AGND
-12V
DA+5V
+12V -12V
+5V
AGND(MIC)
H/P GND
VGND
HDMI
TRANSCEIVER
TRANS
VKK
DAC
NETWORK
DAC
PLD
PCM1690
PCM5100
DGND
PRE GND
DGND
DGND(USB)
DGND
ZONE2 OUT
HDMI 2.0
ADV7623
MN864778
ETHERNET
CY920
DGND DGND
HDMI B'D
DGND
DGND(USB)
DGND
AGND(MIC)
DGND
DGND(USB)
DGND(HDMI)
AGND
VGND(RET_GND)
PCM9211
FUCTION
ENCODER B'D
ENCODER
AGND
SBL GND SBR GND
PRE SBL GND PRE SBR GND
ZONE2
VOLUME
BD3812F
SBL GND SBR GND
MN864778A
DIFF-AMP B'D
RLY_ S/W GND
RLY_GND
DA_GND
A GND / PRE RETURN GND
AGND DAGND
CURRENT DET GND
DA_GND
VGND(RET_GND)
AGND
RLY_GND
DGND
OPEN
OPEN
OPEN
OPEN
OPEN
OPEN
93

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
