Denon AVR-S700W Service Manual

POWER DIAGRAM
MAIN+B
MAIN-B
AC CORD
RELAY
!
!
!
MAIN TRANS
S2 TOTAL : 562.66mA
!
S4(FILAMENT)
S3(FL+Vdisp)
S2(+12V,-12V)
S1(AMP+B,-B)
KIA7812BPI
KIA7912PI
FILAMENT AC
A+12V
DA+5V
A-12V
Vdisp(+37V)
KIA7805BPI
+5.2V
MAIN PWR ON
TUNER+5V
FILAMENT AC
V-5V
V+5V
MM1Z7V5
VOLUME IC
(NJU72340A)
VOLUME IC
(NJU72340A)
MCU_3V3/MICOM
SWM3.3V/LEVEL_CHG
DA3.3V/DIR,DSP
EN5339QI(+1.1V)
EN5339QI(+3.3V)
NJM2845DL133
CEC5V
CEC3V3/HDMI
DA1.1V/DSP
NET1.2V/NETWORK
D1V8H/HDMI
NET2.5V/NETWORK
D5V/VBUS
DV5V/HDMI
(ADV7623)
(AD8195,MN864778,MN864778A
)
(CY920)
(CY920)
(R5F56108VNFP,R1EX24256BSAS0A,VFD)
(AD8195)
(PCM9211PTR,PCM1690DCAR)
(NJM8080,SPK/H-P/HI-LOW RELAY)
(ADSP21487)
(SN74LVC244APWR,TC74VHC08)
(NJM2595)
25mA
264.66mA
122mA
22mA
50mA
68mA
163mA
571.72mA
1040mA
300mA
982mA
724mA
0.06mA
110mA
* TOTAL (5V): 1120.42mA
EN5339QI(+1.8V)
1000mA
2554.72mA
110.06mA
20.4mA
(NJM2595)
MCU+5V (CVDBLBJEGJ204L)FRONT LED
30mA
1232mA
SMPS Total Current : About 4174mA
NJM2845DL133
45mA
DA+3.3V (PCM5100)
MM1Z5V1
MM1Z5V1
MM1Z7V5
(74VHC4051AFT)SWM5V
0.02mA
79.62mA
490.43mA
INPUT CURRENT (Ref Volage:5.2V)
183mA
NET3.3V/NETWORK
(CX870/CY920 , MX25L25635FM, IPOD AUTH)
604mA
PLD1.8V/PLD
(5M80ZT100C5N)
NET1.8V/NETWORK
(CY920)
(ADSP21487,W9864G6JH,5M80ZT100C5N,TC74VHCU04,MX25L1606EM2I-12G,PCM9211,PCM1690)
MM1Z6V8
MM1Z6V8
ZONE VOLUME IC
(BD3812F)
ZONE VOLUME IC
(BD3812F)
AVR-X1100W E3 ONLY
40mA
210mA
HI+B
LOW-B
CECTX-1V1/HDMI TX
(MN864778)
900mA
EN5339QI(+1.1V)
CECRX-1V1/HDMI RX
(MN864778A)
1200mA
34mA
*DC-DC Effieciency:85%
EN5339QI(+1.2V)
510.87mA
110.06mA
101.18mA
EN5339QI(+2.5V)
1864.45mA
218.94mA
(5.2V)
(5.2V)
(5.2V)
(5.2V)
(5.2V)
(5.2V)
(5.2V)
HI-B
LOW+B
DV3V3
(ADV7623,MX25L3206E/MX25L6406EM2I-12G)
(BT MODULE:CNVIBT-06-02)+3.6V
BD00HA3WEFJ
70mA
339mA
1
3
4
2
S
G
D
12
3 4
AVR-S700W/X1100W VCC DIAGRAM
