Denon AVR-S700W Service Manual

3.5.4. Clearing the Protection History
There are two ways to clear the protection history.
(1) Start Protection History Display Mode. Press the button "
STATUS
" to display the protection history. Press and hold the
button "
DIMMER
" for 3 seconds.
FLD
P R T : D C
Press and hold the button "
DIMMER
" for 3 seconds.
FLD
P R T : C L E A R
The above is displayed and the protection history is cleared.
FLD
N O P R O T E C T
(2) Initialize this unit. ( "See "
Initializing This Unit
" 11 page )
b
Use the method in
3.5.3.(1)
if you do not want to erase your settings from this unit.
Warning Displays by POWER LED
If the power is turned off while a protection is detected, the POWER LED (red) ashes in the following ways as a warning
according to the protection status.
(1) ASO/DC protection: Flashes in 0.5-second cycles (0.25 seconds lit, 0.25 seconds unlit)
(2) THERMAL (A/B) protection: Flashes in 2-second cycles (1 second lit, 1 second unlit)
46

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
