Denon AVR-S700W Service Manual

1.3. File structure on USB Memory
Copy the update les to the USB memory with the following structure:
USB memory root
Model Name Model Area Product ID
AVR-X1100WE3 North America (E3) 000100670100
AVR-X1100WE2/E1 Europe (E2)/Asia (E1) 000100670200
AVR-X1100WE1C China (E1C) 000100670500
AVR-X1100WK Japan (JP) 000100670400
AVR-S700WE3 North America (E3) 000100670700
+ rmwares
+ 000100XXXXXX
+ APLD.bin
+ DSP.bin
+ enc_update.xml
+ GUI.bin
+ IMG.bcd
+ MAIN.bin
1.4. Insert the USB memory in the USB port.
NOTE
：
Remove the LAN cable from this unit when performing updates.
QUICK SELECT
MASTER VOLUME
DIMMER
STATUS
DVD/Blu-ray ONLINE
MEDIA
PLAYER
CBL/SAT
321 4
SETUP MICAUX - HDMI
5V / 1A
Download firmware in
USB flash drive.
55

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
