DISASSEMBLY
• Remove each part in the order of the arrows below.
• Reassemble removed parts in the reverse order.
• Read
"Precautions During Work"
before reassembling removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing the
work. Failure to shape the wires correctly may cause problems such as noise.
FRONT PANEL ASSY
See "DISASSEMBLY"
1. FRONT PANEL ASSY
and "EXPLODED VIEW"
FRONT HDMI PCB
(Ref. No. of EXPLODED VIEW : P1)
FRONT PCB
(Ref. No. of EXPLODED VIEW : P3)
FUNCTION PCB
(Ref. No. of EXPLODED VIEW : P4)
CNT PCB
(Ref. No. of EXPLODED VIEW : P5)
F/H_GUIDE PCB
(Ref. No. of EXPLODED VIEW : P6)
BLUETOOTH PCB
(Ref. No. of EXPLODED VIEW : P16)
TOP COVER
MAIN TRANS
See "DISASSEMBLY"
7. MAIN TRANS
and "EXPLODED VIEW"
MAIN TRANS
(Ref. No. of EXPLODED VIEW : 13)
RADIATOR ASSY
See "DISASSEMBLY"
2. RADIATOR ASSY
and "EXPLODED VIEW"
AMP PCB
(Ref. No. of EXPLODED VIEW : P7)
GUIDE L PCB
(Ref. No. of EXPLODED VIEW : P17)
TOP_GUIDE PCB
(Ref. No. of EXPLODED VIEW : P18)
GUIDE R PCB
(Ref. No. of EXPLODED VIEW : P19)
HDMI PCB ASSY
See "DISASSEMBLY"
3. HDMI PCB ASSY
and "EXPLODED VIEW"
HDMI PCB
(Ref. No. of EXPLODED VIEW : P13)
CX870 MIDDLE PCB
(Ref. No. of EXPLODED VIEW : P20)
CX870 MODULE
(Ref. No. of EXPLODED VIEW : P21)
RS232C PCB
(Ref. No. of EXPLODED VIEW : P14)
RS CNT PCB
(Ref. No. of EXPLODED VIEW : P15)
VIDEO PCB ASSY
See "DISASSEMBLY"
4. VIDEO PCB ASSY
and "EXPLODED VIEW"
VIDEO PCB
(Ref. No. of EXPLODED VIEW : P12)
MAIN PCB ASSY
See "DISASSEMBLY"
5. MAIN PCB ASSY
and "EXPLODED VIEW"
MAIN PCB
(Ref. No. of EXPLODED VIEW : P12)
FRONT CNT PCB
(Ref. No. of EXPLODED VIEW : P11)
INPUT PCB
(Ref. No. of EXPLODED VIEW : P10)
SMPS PCB
See "DISASSEMBLY"
6. SMPS PCB
and "EXPLODED VIEW"
SMPS PCB
(Ref. No. of EXPLODED VIEW : P8)
12
To Next Page
