Check the connection environment
YES
YES
YES
YES
YES
Are the network settings of this unit correct?
Are peripheral devices such as the router and hub connected cor-
rectly?
Are the router settings correct?
Set the IP address, etc. correctly.
If the IP settings are xed, check that no
other devices have the same IP address and
that the subnet mask settings are correct.
Connect the peripheral devices correctly.
Check the instruction manual of the router
and congure the settings correctly.
Check that there are no connection restric-
tions by MAC addresses, etc.
NO
NO
NO
5. Network/Bluetooth/USB
5.1. Cannot connect to the network
Is the LAN cable correctly inserted?
Insert the LAN cable correctly and then turn
on the power again.
NO
Check the connection environment
Checking the unit
90
