Denon AVR-S900W

4. VIDEO PCB
Proceeding : TOP COVER → BACK CHASSIS → HDMI PCB → VIDEO PCB
(1) Remove the connector wire.
5. MAIN PCB
Proceeding : TOP COVER → BACK CHASSIS → HDMI PCB → VIDEO PCB → MAIN PCB
(1) Remove the screws.
Front side
CN5000CN5001CN5004
CN5003
View from the bottom
17
